Sony TRINITRON KV-DA29M81 - Page 84

– 94 –
KV-DA29M81
RM-W105
Ref Pin No. Voltage[v]Ref Pin No. Voltage[v]Ref Pin No. Voltage[v]
A BOARD VOLTAGE LIST AND WAVEFORM
67 0
68 0
69 0
70 0
71 3.3
72 *
73 3.3
74 3.3
75 3.3
76 3.3
77 0
78 3.3
79 0
80 0
81 0
82 0
83 0
84 0
85 0
86 0
87 0
88 0
89 0
90 0
91 0
92 0
93 0
94 0
95 (0.3)[*]
96 0
97 1.1
98 0
99 (5.0)[*]
100 2.0
IC1001 1 5.0
20
30
40
5 4.5
6 (4.0)[4.5]
75.0
85.0
IC1004 1 0
20
30
40
5 3.8
6 3.7
7 3.2
8 3.2
IC1201 1 0.1
20
3 29.3
40
50
6*
7 14.7
8 3.6
9 (10.9)[10.6]
10 30.7
11 30.7
12 14.7
IC2201 1 6.0
2 3.2
3 5.8
4 3.2
5 5.8
6 8.9
7 5.1
80
IC2202 1 6.0
2 3.2
3 5.8
4 3.2
5 5.8
6 8.9
7 5.1
80
IC2203 1 6.0
23.2
35.8
43.2
55.8
68.9
75.1
80
IC2204 1 6.0
23.2
35.8
43.2
55.8
68.9
75.1
80
IC2600 I 12.1
G9.0
O0
V 12.1
IC2601 I 6.8
G0
O5.0
V2.2
IC2603 I 6.4
G0
O 3.3
IC2604 1 2.4
2 3.2
30
4 (*)[1.7]
50
IC2605 I 5.9
G0.1
O1.9
V2.6
IC2607 I 6.1
G0
O 3.3
IC4301 1 1.0
2 3.9
3 4.9
4 2.7
4.000Vp-p
6
50
60
7 3.5
8 2.1
90
10 3.4
11 3.8
12 2.7
13 4.1
14 4.4
15 (4.8)[5.6]
16 4.1
17 4.1
18 3.4
1.520Vp-p
PA L
7
1.600p-p
NTSC
7
19 3.4
1.600Vp-p
8
20 0.9
21 9.0
22 1.1
23 4.0
24 4.2
25 1.7
26 9.0
27 3.7
28 2.9
29 3.4
30 2.7
31 3.1
32 2.8
33 0
34 0.1
35 0
36 3.2
116.0mVp-p
9
37 3.2
108.0mVp-p
10
38 3.2
124.0mVp-p
11
39 0
40 0.8
41 0.8
42 2.3
43 2.9
44 2.5
45 1.1
46 4.9
47 3.7
48 3.5
49 3.5
50 2.1
51 0
52 4.5
53 4.6
