Sony TRINITRON KV-DA29M81 - Voltage Measurement and Waveform

– 93 –
KV-DA29M81
RM-W105
A BOARD VOLTAGE LIST AND WAVEFORM
7-3. VOLTAGE MEASUREMENT AND WAVEFORM
Ref Pin No. Voltage[v]Ref Pin No. Voltage[v]Ref Pin No Voltage[v]
IC001 1 0
20
3 3.2
40
5 1.7
6 3.2
70
80
9 3.0
10 3.2
11 1.7
12 1.7
13 0
14 4.9
15 0
16 0
17 0
18 3.2
19 3.2
20 3.8
21 3.7
22 (0.7)[1.1]
23 0
24 0
25 1.9
26 0
27 3.2
28 0
29 1.7
30 3.2
31 2.8
32 2.8
33 1.9
34 0
35 3.2
36 1.9
37 0
38 1.6
39 3.2
40 0
41 3.2
42 2.4
43 2.3
44 2.3
45 2.9
46 3.5
47 4.9
48 0
49 1.2
50 1.3
51 1.3
52 (0.1)[0.2]
53 1.4
54 1.5
55 1.6
56 1.8
57 1.4
58 1.2
59 1.2
60 4.9
61 0
62 4.5
63 0.4
64 2.0
65 1.4
66 3.5
67 3.5
68 3.5
69 3.5
70 1.5
71 1.4
72 2.1
73 2.1
74 0
1.280Vp-p
2
75 2.1
76 2.1
77 1.5
78 1.8
79 2.1
80 2.1
81 1.4
82 4.8
83 (4.7)[2.0]
84 8.4
85 4.3
86 2.2
87 0.5
88 1.9
89 0
90 2.4
91 2.2
92 (3.3)[3.5]
93 (3.3)[3.5]
94 2.1
95 2.1
96 2.1
97 0
98 4.6
99 0.2
100 0
101 0
102 1.9
103 2.3
104 1.9
105 1.9
106 0
107 3.3
108 2.0
109 2.3
110 2.3
111 0
112 2.2
113 2.8
114 4.9
115 2.5
116 0
117 0
118 *
119 *
3.160Vp-p
1
120 *
121 0
122 3.2
123 0
124 3.2
125 3.1
126 1.7
127 0
128 0
IC004 1 0
2 4.5
30
40.4
54.9
IC005 1 0
2 3.3
30
4 0.2
5 4.9
IC100 I 10.5
G0
O5.0
IC1000 1 (0.3)[0.4]
21.3
34.0
44.0
50
60
70
80
90
10 0
11 0
12 3.3
13 *
14 0
15 *
16 3.3
17 1.7
18 0
19 0
20 0
21 0.1
22 0
23 0
24 1.6
25 0
26 0
27 3.3
28 4.5
29 4.5
30 4.5
31 4.5
32 0
33 0
34 0
35 3.3
36 (0.6)[0.5]
37 (0.6)[0.5]
38 (0.6)[0.5]
39 0.5
40 0
41 3.3
42 0
43 0
44 0
45 0
46 0.5
47 0
48 0
49 0
50 0
51 3.3
52 0
53 0
54 0
55 0
56 0
57 0
58 0
59 0
60 0
61 0
62 0.1
63 0
64 0
65 0
66 0
