Sony Trinitron PVM-9L1 - Specifications

12 (GB)
Video signal
Frequency response
LINE PVM-9L1: 4 MHz +0 dB, –6 dB
(Y signal)
PVM-14L1/PVM-20L1:
8 MHz +0 dB, –6 dB (Y signal)
Picture performance
Normal scan PVM-9L1: 6 % over scan of CRT
effective screen area
PVM-14L1/PVM-20L1: 7 % over
scan of CRT effective screen area
H. linearity Less than 8.0 % (typical)
V. linearity Less than 7.0 % (typical)
Color temperature D65, D93, USER (Adjustable color
temperature: 5000 K to 10000 K)
Resolution PVM-9L1: 250 TV lines
PVM-14L1/PVM-20L1: 600 TV
lines (When Y/C signal is
inputted)
Input connectors
LINE input connectors (PVM-9L1)
Y/C input 4-pin mini-DIN (×1)
See the pin assignment on page 13 (GB).
VIDEO input BNC type (×1), 1Vp-p +3 dB,
–6 dB, negative synchronization
AUDIO input
Phono jack (×1), –5 dBu
a)
, 47 kΩ or
higher
LINE A/B input connector (PVM-14L1/PVM-20L1)
Y/C input 4-pin mini-DIN (×2)
See the pin assignment on the page
13 (GB).
VIDEO input BNC connector (×2), 1Vp-p +3 dB,
–6 dB, negative synchronization
AUDIO input
Phono jack (×2), –5 dBu
a)
, 47 kΩ or
higher
Remote input terminal
Parallel remote
Modular connector 8-pin (×1)
Specifications
a) 0 dBu = 0.775 Vr.m.s.
........................................................................................................................................................................................................
Output connectors
LINE output connecters (PVM-9L1)
Y/C output 4-pin mini-DIN (×1) Loop-through,
75 Ω automatic terminal function
VIDEO output
BNC type (×1) Loop-through,
75 Ω automatic terminal function
AUDIO output
Phono jack (×1) Loop-through
LINE A output connecters (PVM-14L1/PVM-20L1)
Y/C output 4-pin mini-DIN (×1) Loop-through,
75 Ω automatic terminal function
VIDEO output
BNC type (×1) Loop-through, 75 Ω
automatic terminal function
AUDIO output
Phono jack (×1) Loop-through
Built-in speaker output
0.8 W (monaural)
General
CRT Trinitron P22 luminescent material
Power consumption
PVM-9L1: 40 W, 0.6 to 0.3A
PVM-14L1: 68 W, 1.1 to 0.4A
PVM-20L1: 75 W, 1.2 to 0.4A
Power requirement
100 to 240 V AC, 50/60Hz
Peak inrush current
PVM-9L1:
(1)Power ON, current probe
method: 93 A (240 V)
(2)Hot switching inrush current,
measured in accordance with
European standard EN55103-1:
41 A (230 V)
PVM-14L1:
(1)Power ON, current probe
method: 93 A (240 V)
(2)Hot switching inrush current,
measured in accordance with
European standard EN55103-1:
42 A (230 V)
