Sony Trinitron PVM-9L1 - Dimensions; Pin Assignment

13 (GB)
PVM-20L1:
(1)Power ON, current probe
method: 93 A (240 V)
(2)Hot switching inrush current,
measured in accordance with
European standard EN55103-1:
42 A (230 V)
Operating conditions
Temperature 0 to +35°C (32°F to 95°F)
Humidity 30 to 85% (no condensation)
Pressure 700 hPa to 1060 hPa
Storage and transport conditions
Temperature –10 to +40°C (14°F to 104°F)
Humidity 0 to 90%
Pressure 700 hPa to 1060 hPa
Dimensions (w/h/d)
PVM-9L1:
Approx. 217 × 218 × 350 mm
(8
5
⁄8 × 8
5
⁄8 × 13
7
⁄8 inches)
PVM-14L1:
Approx. 346 × 340 × 414 mm
(13
5
⁄8 × 13
1
⁄2 × 16
3
⁄8 inches)
PVM-20L1:
Approx. 449 × 441 × 502 mm
(17
3
⁄4 × 17
3
⁄8 × 19
7
⁄8 inches)
Mass PVM-9L1:
Approx. 6.3 kg (13 lb 15 oz)
PVM-14L1:
Approx. 15 kg (33 lb 2 oz)
PVM-20L1:
Approx. 28 kg (61 lb 12 oz)
Accesory supplied AC power cord (1)
Operating Instructions (1)
Design and specifications are subject to change
without notice.
Pin assignment
Y/C IN connector (4-pin mini-DIN)
Pin
number
1
2
3
4
PARALLEL REMOTE terminal
Modular connector (8 pin)
Pin
number
1
2
3
4
5
6
7
8
Wiring required to use the Remote Control
Connect the function you want to use with a Remote
Control to the Ground (Pin 5).
Signal
Y-input
CHROMA-input
Subcarrier-input
GND for Y-input
GND for CHROMA-
input
Description
1 Vp-p, sync negative, 75
ohms
286m Vp-p (NTSC),
300m Vp-p (PAL),
burst
Delay time between Y and
C: within 0 ± 100 nsec.,
75 ohms
GND
GND
Functions
PVM-14L1/PVM-20L1
Indicates the LINE A
input signal
Indicates the LINE B
Open
Open
GND (Earth)
Open
Open
Select aspect ratio
16:9
PVM-9L1
Open
Open
Open
Open
GND (Earth)
Open
Open
Select aspect ratio
16:9
18
21
34
*
