Sony TRINITRON RM-Y194 - Service Position

10
KV-21FK120
KV-21FK120
1
Depress the PC Board clips to release
KR Board.
2
Disconnect the CN515 cable
3
Press on catch tab to release A Board
and gently pull away from the set.
1-3. SERVICE POSITION
CV Board
A Board
