4-5. SERVICE DATA LIST
1H-SIZE HSIZ
H SIZE(EW DC) : YUV OFFSET
41
2 H-AFC-2 phase HPOS
H POSITION : YUV OFFSET
31
3 VSIZE VSIZ
V RAMP SIZE : YUV OFFSET
31
4 VPOSI VPOS
V POSITION(RAMP DC) not useful : YUV OFFSET
35
5LINI VLIN
V LINEARITY
28
6 S CORRECTION SCOR
S CORRECTION
45
7BOW VBOW
BOW
36
8 ANGLE VANG
ANGLE
44
9 TRAPESIUM TRAP
EW TRAPESIUM
29
10 PARABOLA PAMP
EW PIN
47
11 UPPER CORNER UPIN
UPPER PIN
31
12 LOWER CORNER LPIN
LOWER PIN
29
13 (TROT) TROT
TROT
109
14 FBPBL
K
HBL
K
H BLK mode select
00
15 HBLK R POS RBL
K
HBLK rear timing : YUV OFFSET
09
16 HBLK F POS LBL
K
HBLK front timing : YUV OFFSET
35
17 VBLK POS VBL
K
V BLK width
00
18 Macro OFF HMS
K
TOP VEND(when MACROVISION) prevent OFF
00
19 HOUT DUTY HDW
H PULSE WIDTH(25u/19u)
01
20 H AFC Gain AFC
AFC GAIN
00
21 H Charge pump AFC1
AFC1 TIME CONSTANT
03
22 AFC1 PULLIN AFCW
AFC1 PULL IN WIDE
00
23 V CD MODE CDMD
V DET WINDOW SW TIMING
01
24 SYNC SLICE LVL(H) HSS
SYNC SLICE LEVEL(H sepa)
00
25 SYNC SLICE LVL(L) VSS
SYNC SLICE LEVEL(V sepa)
03
26 AUTO SLICE DOWN SLDN
Auto Slice level DOWN
00
27 AUTO SLICE UP SLUP
Auto Slice level UP
00
28 VJPSW JPSW
Jump SW
00
29 HVCO FREERUN OFFSET HOSC
H VCO fo offset ADJUST OFFSET
07
30 EHT EHT
EHT
04
31 EHT GAIN EHTG
EHT MODE
01
