KV-21FK120
KV-21FK120
1 VM GAIN(Off) VMOF
VM LEVEL at "Off" Setting
02
2 VM GAIN(Low) VMLO
VM LEVEL at "Low" Setting
04
3 VM GAIN(High) VMHI
VM LEVEL at "High" Setting
08
4VM DELAY VMDL
VM DELAY
06
5 VM POL VMPL
VM PORALITY
00
6VM WIDTH VMWD
VM WIDTH
00
7 VM CORING LEVEL VMCL
VM CORING LEVEL
00
8 VM MAX VMMX
VM LIMITER LEVEL
15
9 KILLER LEVEL CKLV
COLOR KILLER VTH YUV/notYUV
01/00
10 FORCE KILLER CKON
FORCE KILLER
00
11 ALFA ALFA
ADAPTIVE DET SENSITIVITY
02
12 MANEXP YCMD
YC SEPA FORCE SELECT
(00:ADAPTIVE 01:H 10:V 11:HV)
00
13 V APERTURE CORING LV VACL
V APERTURE CORING LEVEL
00
14 V APERTURE GAIN VAGA
V APERTURE GAIN LEVEL
05
15 V APERTURE MAX GAIN VAMX
V APERTURE LIMITER LEVEL
05
16 GAMMA GAMM
GAMMA(00:no <-->11:deep)
01
17 Y DELAY YDLY
Y DELAY TIME YUV/notYUV
01/03
18 C DELAY CDLY
C DELAY
00
19 Y Mute YOFF
Y OUTPUT MUTE
00
20 SAW FILTER(7.2MHzBPF) CBPF
C BPF fo HI
00
21 BGP POS BGPP
BGP(for C DECODER)TIMING YUV/notYUV
09/28
22 G DRIVE OFFSET GDOF
G DRIVE OFFSET only Color Temp. "Warm"
09
23 B DRIVE OFFSET BDOF
B DRIVE OFFSET only Color Temp. "Warm"
14
24 GCUT OFFSET GCOF
GCUT CMP DATA OFFSET only Color Temp. "Warm"
11
25 BCUT OFFSET BCOF
BCUT CMP DATA OFFSET only Color Temp. "Warm"
28
26 DCTRAN VTH<6:0> DCTV
DCTRANSFER VTH
30
27 DCTRAN GAIN<4:0> DCTG
DCTRANSFER GAIN
15
1 COLOR SCOL
SUB COLOR LEVEL
16
2 SHARP NOISE CORING LV SHCL
SHARPNESS CORING LEVEL
15
3 SHARPNESS MAX GAIN SHMX
SHARPNESS LIMITTER LEVEL
07
4 YNR NOISE CORING LV YNRC
YNR LIMITER LEVEL
07
5 VM GAIN(High) VMHI
VM LEVEL at "High" Setting
10
6 VM CORING LEVEL VMCL
VM CORING LEVEL
00
7 VM MAX VMMX
VM LIMITER LEVEL
07
8 V APERTURE MAX GAIN VAMX
V APERTURE LIMITER LEVEL
00
9 GAMMA GAMM
GAMMA(00:no <-->11:deep)
00
10 YNR SW YNRS
YNR ON
01
11 WEAK_SIG_VTH WSTH
WEAK_SIGNAL VTH
07
12 WEAK SIG VIDEO ATT WSVA
WEAK SIGNAL VIDEO ATT
00
13 WEAK SIG CHROMA ATT WSCA
WEAK SIGNAL CHROMA ATT
05
14 THRNZV1 NRCH
NOISE DET TIME CONSTANT
00
15 THRNZV2 NRCL
NOISE DET TIME CONSTANT
16
16 THRNZH1 NRVL
NOISE DET VTH
02
17 THRNZH2 NRVH
NOISE DET VTH
00
18 NR COUNTER IPNC
Intelligent Picture "DETNZ" Counter
02
19 NR Vsync Counter IPNV
Intelligent Picture "DETNZ" Counter
10
