Sony TRINITRON RM-Y194 - Page 49

49
KV-21FK120
KV-21FK120
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identified by shading
and
!
mark are critical for safety. Replace only
with part number specified.
A
C214 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C220 1-125-891-11 CERAMIC CHIP 0.47µF 10% 10V
C301 1-126-956-91 ELECT 0.1µF 20% 50V
C302 1-126-956-91 ELECT 0.1µF 20% 50V
C303 1-126-956-91 ELECT 0.1µF 20% 50V
C304 1-126-956-91 ELECT 0.1µF 20% 50V
C305 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C306 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C307 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C309 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C313 1-126-956-91 ELECT 0.1µF 20% 50V
C318 1-126-964-11 ELECT 10µF 20% 50V
C319 1-126-964-11 ELECT 10µF 20% 50V
C325 1-162-967-11 CERAMIC CHIP 0.0033µF 10% 50V
C326 1-164-505-11 CERAMIC CHIP 2.2µF 16V
C328 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C330 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C337 1-162-919-11 CERAMIC CHIP 22pF 5% 50V
C351 1-164-315-11 CERAMIC CHIP 470pF 5% 50V
C370 1-162-968-11 CERAMIC CHIP 0.0047µF 10% 50V
C390 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C400 1-128-934-91 CERAMIC CHIP 0.33µF 20% 10V
C401 1-164-227-11 CERAMIC CHIP 0.022µF 10% 25V
C402 1-164-174-11 CERAMIC CHIP 0.0082µF 10% 25V
C403 1-162-967-11 CERAMIC CHIP 0.0033µF 10% 50V
C404 1-162-967-11 CERAMIC CHIP 0.0033µF 10% 50V
C405 1-164-677-11 CERAMIC CHIP 0.033µF 10% 16V
C406 1-164-677-11 CERAMIC CHIP 0.033µF 10% 16V
C407 1-162-965-11 CERAMIC CHIP 0.0015µF 10% 50V
C408 1-162-965-11 CERAMIC CHIP 0.0015µF 10% 50V
C409 1-127-715-91 CERAMIC CHIP 0.22µF 10% 16V
C410 1-127-715-91 CERAMIC CHIP 0.22µF 10% 16V
C411 1-128-934-91 CERAMIC CHIP 0.33µF 20% 10V
C412 1-126-960-11 ELECT 1µF 20% 50V
C413 1-126-963-11 ELECT 4.7µF 20% 50V
C414 1-126-961-11 ELECT 2.2µF 20% 50V
C415 1-126-963-11 ELECT 4.7µF 20% 50V
C416 1-126-960-11 ELECT 1µF 20% 50V
C418 1-126-963-11 ELECT 4.7µF 20% 50V
C419 1-125-891-11 CERAMIC CHIP 0.47µF 10% 10V
C420 1-126-960-11 ELECT 1µF 20% 50V
C421 1-126-965-91 ELECT 22µF 20% 50V
C422 1-126-960-11 ELECT 1µF 20% 50V
C423 1-126-963-11 ELECT 4.7µF 20% 50V
C424 1-125-891-11 CERAMIC CHIP 0.47µF 10% 10V
C430 1-126-963-11 ELECT 4.7µF 20% 50V
C431 1-126-963-11 ELECT 4.7µF 20% 50V
C436 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C450 1-126-942-61 ELECT 1000µF 20% 25V
C451 1-126-959-11 ELECT 0.47µF 20% 50V
C452 1-126-960-11 ELECT 1µF 20% 50V
C457 1-127-715-91 CERAMIC CHIP 0.22µF 10% 16V
C458 1-127-715-91 CERAMIC CHIP 0.22µF 10% 16V
C460 1-126-943-11 ELECT 2200µF 20% 25V
C461 1-126-943-11 ELECT 2200µF 20% 25V
C462 1-126-943-11 ELECT 2200µF 20% 25V
C463 1-126-943-11 ELECT 2200µF 20% 25V
C501 1-126-959-11 ELECT 0.47µF 20% 50V
C502 1-102-112-00 CERAMIC 330pF 10% 50V
C503 1-106-383-00 MYLAR 0.047µF 10% 200V
C504 1-102-228-00 CERAMIC 470pF 10% 500V
C505 1-102-228-00 CERAMIC 470pF 10% 500V
!
C506 1-117-214-11 CERAMIC 0.001µF 10% 2KV
!
C507 1-117-642-11 FILM 8200pF 3% 1.2KV
!
C508 1-129-722-00 FILM 0.047µF 5% 630V
C509 1-126-964-11 ELECT 10µF 20% 50V
C510 1-117-214-11 CERAMIC 0.001µF 10% 2KV
C511 1-115-521-11 FILM 0.82µF 5% 250V
C512 1-104-987-11 MYLAR 0.001µF 5% 200V
C513 1-106-383-00 MYLAR 0.047µF 10% 200V
C514 1-115-519-11 FILM 0.56µF 5% 250V
C515 1-107-651-11 ELECT 4.7µF 20% 250V
C519 1-216-864-11 SHORT CHIP
C520 1-126-965-91 ELECT 22µF 20% 50V
C521 1-126-960-11 ELECT 1µF 20% 50V
C522 1-102-244-00 CERAMIC 220pF 10% 500V
C523 1-165-529-11 MYLAR 0.22µF 10 275V
C525 1-164-646-11 CERAMIC 2200pF 10% 500V
C526 1-102-244-00 CERAMIC 220pF 10% 500V
C527 1-107-645-11 ELECT 22µF 20% 200V
C529 1-164-690-91 CERAMIC CHIP 0.0022µF 5% 50V
C534 1-164-315-11 CERAMIC CHIP 470pF 5% 50V
C535 1-137-372-11 MYLAR 0.022µF 5% 50V
C536 1-164-315-11 CERAMIC CHIP 470pF 5% 50V
C537 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C539 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
