Sony TRINITRON RM-Y194 - Page 53

53
KV-21FK120
KV-21FK120
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identified by shading
and
!
mark are critical for safety. Replace only
with part number specified.
A
COIL
L002 1-239-803-11 ENCAPSULATED COMPONENT
L003 1-239-803-11 ENCAPSULATED COMPONENT
L004 1-239-803-11 ENCAPSULATED COMPONENT
L005 1-239-803-11 ENCAPSULATED COMPONENT
L006 1-414-273-11 INDUCTOR 100µH
L007 1-414-273-11 INDUCTOR 100µH
L008 1-414-857-11 INDUCTOR 100µH
L009 1-414-857-11 INDUCTOR 100µH
L010 1-414-267-21 INDUCTOR 10µH
L011 1-239-803-11 ENCAPSULATED COMPONENT
L101 1-414-229-11 FERRITE 0µH
!
L510 1-406-981-21 INDUCTOR 470µH
L513 1-406-677-11 INDUCTOR 10MH
L515 1-412-552-11 INDUCTOR 2.2MH
L525 1-409-955-31 INDUCTOR 8MH
L527 1-410-397-21 FERRITE 1.1µH
L588 1-412-528-11 INDUCTOR 18µH
L606 1-412-525-31 INDUCTOR 10µH
L607 1-412-525-31 INDUCTOR 10µH
L608 1-412-533-21 INDUCTOR 47µH
L609 1-412-525-31 INDUCTOR 10µH
PHOTO COUPLER
!
PH602 8-749-010-64 PHOTO COUPLER PC123F2J000F
IC LINK
PS401 1-576-337-21 IC LINK 2.7A 50V
TRANSISTOR
Q002 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q004 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q005 8-729-600-22 TRANSISTOR 2SA1235-F
Q006 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q008 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q009 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q300 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q301 8-729-600-22 TRANSISTOR 2SA1235-F
Q303 8-729-600-22 TRANSISTOR 2SA1235-F
Q304 8-729-600-22 TRANSISTOR 2SA1235-F
Q305 8-729-600-22 TRANSISTOR 2SA1235-F
Q306 8-729-600-22 TRANSISTOR 2SA1235-F
Q316 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q390 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q391 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q404 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q411 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q420 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q421 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q501 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
Q502 8-729-140-50 TRANSISTOR 2SC3209LK
Q503 8-729-600-22 TRANSISTOR 2SA1235-F
Q504 8-729-120-28 TRANSISTOR 2SC1623-L5L6
!
Q506 6-550-042-01 TRANSISTOR 2SD2627LS-YB11
Q519 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q521 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
Q522 8-729-053-87 TRANSISTOR KTC4370A
Q531 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q533 8-729-600-22 TRANSISTOR 2SA1235-F
Q572 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q573 8-729-600-22 TRANSISTOR 2SA1235-F
Q578 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q590 6-550-362-01 TRANSISTOR KTA1279
Q600 8-729-053-36 TRANSISTOR 2SK2640-01MR-F122
Q601 8-729-053-36 TRANSISTOR 2SK2640-01MR-F122
Q604 8-729-600-22 TRANSISTOR 2SA1235-F
Q608 8-729-922-37 TRANSISTOR 2SD2144S-UVW
Q650 6-550-409-01 TRANSISTOR KSC2383-O
Q860 8-729-120-28 TRANSISTOR 2SC1623-L5L6
RESISTOR
R002 1-216-864-11 SHORT CHIP
R003 1-216-821-11 METAL CHIP 1K 5% 1/10W
R004 1-216-817-11 METAL CHIP 470 5% 1/10W
R005 1-400-427-21 FERRITE 0µH
R006 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R007 1-400-427-21 FERRITE 0µH
R015 1-216-833-11 METAL CHIP 10K 5% 1/10W
R027 1-218-732-11 METAL CHIP 47K 0.50% 1/10W
R028 1-249-409-11 CARBON 220 5% 1/4W
R029 1-249-409-11 CARBON 220 5% 1/4W
R030 1-249-409-11 CARBON 220 5% 1/4W
R031 1-216-813-11 METAL CHIP 220 5% 1/10W
