Sony TRINITRON RM-Y194 - Page 55

55
KV-21FK120
KV-21FK120
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identified by shading
and
!
mark are critical for safety. Replace only
with part number specified.
A
R319 1-216-813-11 METAL CHIP 220 5% 1/10W
R320 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R321 1-247-807-31 CARBON 100 5% 1/4W
R322 1-218-684-11 METAL CHIP 470 0.50% 1/10W
R323 1-215-415-00 METAL 560 1% 1/4W
R324 1-216-821-11 METAL CHIP 1K 5% 1/10W
R325 1-216-864-11 SHORT CHIP
R326 1-400-427-21 FERRITE 0µH
R328 1-400-427-21 FERRITE 0µH
R335 1-216-813-11 METAL CHIP 220 5% 1/10W
R337 1-216-801-11 METAL CHIP 22 5% 1/10W
R338 1-216-864-11 SHORT CHIP
R351 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R352 1-216-853-11 METAL CHIP 470K 5% 1/10W
R363 1-218-285-11 METAL CHIP 75 5% 1/10W
R364 1-218-285-11 METAL CHIP 75 5% 1/10W
R370 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R371 1-216-849-11 METAL CHIP 220K 5% 1/10W
R372 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R382 1-216-863-11 METAL CHIP 3.3M 5% 1/10W
R390 1-216-864-11 SHORT CHIP
R391 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R392 1-216-818-11 METAL CHIP 560 5% 1/10W
R393 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R394 1-216-833-11 METAL CHIP 10K 5% 1/10W
R400 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R401 1-216-809-11 METAL CHIP 100 5% 1/10W
R403 1-216-809-11 METAL CHIP 100 5% 1/10W
R404 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R405 1-216-833-11 METAL CHIP 10K 5% 1/10W
R408 1-216-864-11 SHORT CHIP
R409 1-216-864-11 SHORT CHIP
R410 1-216-833-11 METAL CHIP 10K 5% 1/10W
R411 1-216-833-11 METAL CHIP 10K 5% 1/10W
R421 1-216-864-11 SHORT CHIP
R422 1-216-833-11 METAL CHIP 10K 5% 1/10W
R423 1-216-813-11 METAL CHIP 220 5% 1/10W
R424 1-216-841-11 METAL CHIP 47K 5% 1/10W
R425 1-216-833-11 METAL CHIP 10K 5% 1/10W
R427 1-216-841-11 METAL CHIP 47K 5% 1/10W
R429 1-216-841-11 METAL CHIP 47K 5% 1/10W
R430 1-216-845-11 METAL CHIP 100K 5% 1/10W
R431 1-216-845-11 METAL CHIP 100K 5% 1/10W
R433 1-216-809-11 METAL CHIP 100 5% 1/10W
R434 1-216-864-11 SHORT CHIP
R442 1-216-809-11 METAL CHIP 100 5% 1/10W
R450 1-249-425-11 CARBON 4.7K 5% 1/4W
R499 1-216-845-11 METAL CHIP 100K 5% 1/10W
R501 1-249-411-11 CARBON 330 5% 1/4W
R502 1-249-425-11 CARBON 4.7K 5% 1/4W
R503 1-215-921-11 METAL OXIDE 4.7K 5% 3W
R504 1-249-425-11 CARBON 4.7K 5% 1/4W
R507 1-216-833-11 METAL CHIP 10K 5% 1/10W
R510 1-260-320-11 CARBON 220 5% 1/2W
R512 1-215-910-00 METAL OXIDE 68 5% 3W
R513 1-215-913-11 METAL OXIDE 220 5% 3W
R514 1-215-910-00 METAL OXIDE 68 5% 3W
R515 1-215-886-11 METAL OXIDE 100 5% 2W
R517 1-218-883-11 METAL CHIP 33K 0.50% 1/10W
R518 1-216-833-11 METAL CHIP 10K 5% 1/10W
R519 1-218-877-11 METAL CHIP 18K 0.50% 1/10W
R520 1-216-833-11 METAL CHIP 10K 5% 1/10W
R521 1-216-819-11 METAL CHIP 680 5% 1/10W
R522 1-249-411-11 CARBON 330 5% 1/4W
R524 1-218-867-11 METAL CHIP 6.8K 0.50% 1/10W
R525 1-215-861-00 METAL OXIDE 47 5% 1W
R526 1-218-724-11 METAL CHIP 22K 0.50% 1/10W
R527 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
!
R528 1-218-712-11 METAL CHIP 6.8K 0.50% 1/10W
R529 1-218-724-11 METAL CHIP 22K 0.50% 1/10W
R530 1-218-873-11 METAL CHIP 12K 0.50% 1/10W
R533 1-218-702-11 METAL CHIP 2.7K 0.50% 1/10W
R534 1-218-720-11 METAL CHIP 15K 0.50% 1/10W
R535 1-218-865-11 METAL CHIP 5.6K 0.50% 1/10W
R536 1-216-833-11 METAL CHIP 10K 5% 1/10W
R537 1-216-857-11 METAL CHIP 1M 5% 1/10W
R538 1-216-851-11 METAL CHIP 330K 5% 1/10W
R539 1-216-864-11 SHORT CHIP
R540 1-249-429-11 CARBON 10K 5% 1/4W
R541 1-218-720-11 METAL CHIP 15K 0.50% 1/10W
R542 1-215-445-00 METAL 10K 1% 1/4W
R543 1-216-351-00 METAL OXIDE 1.5 5% 1W
R544 1-249-389-11 CARBON 4.7 5% 1/4W
R545 1-215-890-11 METAL OXIDE 470 5% 2W
R546 1-249-385-11 CARBON 2.2 5% 1/4W
