57
KV-21FK120
KV-21FK120
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identified by shading
and
!
mark are critical for safety. Replace only
with part number specified.
CV
R803 1-218-719-11 METAL CHIP 13K 0.50% 1/10W
R804 1-249-435-11 CARBON 33K 5% 1/4W
R812 1-218-716-11 METAL CHIP 10K 0.50% 1/10W
R813 1-218-716-11 METAL CHIP 10K 0.50% 1/10W
R814 1-218-736-11 METAL CHIP 68K 0.50% 1/10W
R815 1-218-732-11 METAL CHIP 47K 0.50% 1/10W
R850 1-215-453-00 METAL 22K 1% 1/4W
R851 1-216-821-11 METAL CHIP 1K 5% 1/10W
R852 1-218-875-11 METAL CHIP 15K 0.50% 1/10W
R860 1-216-833-11 METAL CHIP 10K 5% 1/10W
R861 1-216-833-11 METAL CHIP 10K 5% 1/10W
R862 1-216-813-11 METAL CHIP 220 5% 1/10W
R893 1-216-864-11 SHORT CHIP
REL
AY
RY501 1-755-198-11 RELAY, AC POWER
!
RY600 1-755-395-11 RELAY (AC POWER)
SWITCH
SW515 1-572-707-11 SWITCH, LEVER
TRANSFORMER
T505 1-433-836-11 TRANSFORMER, HORIZONTAL DRIVE
!
T511 1-435-079-21 TRANSFORMER, HORIZONTAL LINEAR
!
T585 1-453-316-21 FBT ASSY NX-1748//X
!
T601 1-435-617-11 TRANSFORMER, LINE FILTER
!
T602 1-435-675-11 TRANSFORMER, STANDBY
!
T603 1-439-898-21 CONVERTER TRANSFORMER
THERMIS
TOR
!
THP501 1-809-539-11 THERMISTOR, POSITIVE
TUNER
!
TU101 8-598-593-70 TUNER, FSS BTF-WA421
VARISTOR
!
VDR600 1-810-974-21 VARISTOR
CRYSTAL
X001 1-795-006-21 VIBRATOR, CRYSTAL
X301 1-781-377-21 VIBRATOR, CRYSTAL
CV
* A-1410-919-A CV (VAR) BOARD, MOUNTED
4-382-854-11 SCREW (M3X10), P, SW (+)
CA
PACITOR
C901 1-107-667-11 ELECT 2.2µF 20% 400V
C902 1-130-491-00 MYLAR 0.047µF 5% 50V
C903 1-126-935-11 ELECT 470µF 20% 16V
C904 1-130-471-00 MYLAR 0.001µF 5% 50V
C905 1-106-383-00 MYLAR 0.047µF 10% 200V
C906 1-130-471-00 MYLAR 0.001µF 5% 50V
C907 1-107-638-11 ELECT 33µF 20% 160V
C908 1-126-935-11 ELECT 470µF 20% 16V
C909 1-161-830-00 CERAMIC 0.0047µF 500V
C910 1-104-999-11 MYLAR 0.1µF 5% 200V
C911 1-104-665-11 ELECT 100µF 20% 25V
C912 1-126-942-61 ELECT 1000µF 20% 25V
C914 1-130-491-00 MYLAR 0.047µF 5% 50V
C915 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C1751 1-107-652-11 ELECT 10µF 20% 250V
C1752 1-115-350-51 CERAMIC 0.0047µF 2KV
C1753 1-137-528-11 MYLAR 0.1µF 10% 250V
C1754 1-102-074-00 CERAMIC 0.001µF 10% 50V
C1755 1-107-649-11 ELECT 2.2µF 20% 250V
C1774 1-126-960-11 ELECT 1µF 20% 50V
C1775 1-126-935-11 ELECT 470µF 20% 16V
C1777 1-126-963-11 ELECT 4.7µF 20% 50V
C1778 1-126-947-11 ELECT 47µF 20% 35V
CONNEC
TOR
* CN903 1-564-506-11 PLUG, CONNECTOR 3P
CN1707 1-564-506-11 PLUG, CONNECTOR 3P
* CN1752 1-564-512-11 PLUG, CONNECTOR 9P
* CN1753 1-785-879-21 ONE TOUCH CONNECTOR
CN1755 1-695-915-11 TAB (CONTACT)
A
