59
KV-21FK120
KV-21FK120
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identified by shading
and
!
mark are critical for safety. Replace only
with part number specified.
R909 1-260-312-11 CARBON 47 5% 1/2W
R910 1-216-476-11 METAL OXIDE 180 5% 3W
R911 1-216-799-11 METAL CHIP 15 5% 1/10W
R912 1-216-813-11 METAL CHIP 220 5% 1/10W
R913 1-216-799-11 METAL CHIP 15 5% 1/10W
R914 1-216-814-11 METAL CHIP 270 5% 1/10W
R915 1-216-821-11 METAL CHIP 1K 5% 1/10W
R916 1-216-821-11 METAL CHIP 1K 5% 1/10W
R917 1-216-821-11 METAL CHIP 1K 5% 1/10W
R918 1-216-809-11 METAL CHIP 100 5% 1/10W
R919 1-216-809-11 METAL CHIP 100 5% 1/10W
R920 1-216-820-11 METAL CHIP 820 5% 1/10W
R921 1-216-833-11 METAL CHIP 10K 5% 1/10W
R922 1-249-397-11 CARBON 22 5% 1/4W
R923 1-249-401-11 CARBON 47 5% 1/4W
R1756 1-260-328-11 CARBON 1K 5% 1/2W
R1757 1-260-328-11 CARBON 1K 5% 1/2W
R1758 1-260-328-11 CARBON 1K 5% 1/2W
R1760 1-260-123-11 CARBON 100K 5% 1/2W
R1761 1-216-395-00 METAL OXIDE 3.3 5% 3W
R1763 1-247-807-31 CARBON 100 5% 1/4W
R1764 1-247-807-31 CARBON 100 5% 1/4W
R1765 1-247-807-31 CARBON 100 5% 1/4W
R1766 1-247-807-31 CARBON 100 5% 1/4W
R1767 1-247-807-31 CARBON 100 5% 1/4W
R1768 1-247-807-31 CARBON 100 5% 1/4W
R1770 1-260-132-11 CARBON 560K 5% 1/2W
R1778 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1780 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1781 1-216-838-11 METAL CHIP 27K 5% 1/10W
R1785 1-249-399-11 CARBON 33 5% 1/4W
R1787 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1788 1-249-421-11 CARBON 2.2K 5% 1/4W
R1789 1-249-425-11 CARBON 4.7K 5% 1/4W
VARIABLE RESISTOR
RV1701 1-238-019-11 RES, ADJ, METAL FILM 47K
!
RV1750 1-241-656-11 RES, ADJ, METAL FILM 110M
HK
* A-1109-540-A HK BOARD, MOUNTED
CAPACITOR
C2001 1-104-665-11 ELECT 100µF 20% 25V
C2234 1-126-960-11 ELECT 1µF 20% 50V
C2235 1-126-960-11 ELECT 1µF 20% 50V
C2239 1-115-350-51 CERAMIC 0.0047µF 2KV
C2240 1-115-350-51 CERAMIC 0.0047µF 2KV
C2401 1-126-960-11 ELECT 1µF 20% 50V
C2402 1-126-960-11 ELECT 1µF 20% 50V
C2411 1-101-004-00 CERAMIC 0.01µF 50V
C2412 1-101-004-00 CERAMIC 0.01µF 50V
CONNECTOR
* CN2402 1-564-509-11 PLUG, CONNECTOR 6P
DIODE
D2001 8-719-109-89 DIODE RD5.6ESB2
D2002 8-719-070-80 DIODE LNK0120022G
D2003 8-719-109-89 DIODE RD5.6ESB2
D2004 8-719-109-89 DIODE RD5.6ESB2
D2005 8-719-109-89 DIODE RD5.6ESB2
D2233 8-719-108-12 DIODE RD9.1EW
D2235 8-719-108-12 DIODE RD9.1EW
D2236 8-719-108-12 DIODE RD9.1EW
D2401 8-719-108-12 DIODE RD9.1EW
D2402 8-719-108-12 DIODE RD9.1EW
IC
IC2001 8-742-212-20 HYB IC SBX3081-71
JACK
J2231 1-816-473-11 JACK, SMALL TYPE
J2401 1-568-267-21 JACK
J2402 1-568-267-21 JACK
CV
HK
