Sony WM-EX921 Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
28
WM-EX921
< IC >
IC301 8-759-579-12 IC TA2123AF (EL)
IC303 8-759-488-80 IC NJM2185AV-TE2
IC601 8-759-553-51 IC LB1994M-TLM
IC701 8-759-553-28 IC XC6383C251ML
IC704 8-759-572-21 IC S-80808ANNP-E7Y-T2
IC705 6-800-620-01 IC ML63514-025TBZ060
< JACK >
J301 1-779-867-81 JACK
(i (HEADPHONE WITH REMOTE CONTROL))
< COIL >
L701 1-412-032-11 INDUCTOR CHIP 100uH
< PHOTO REFLECTOR >
PH701 8-749-016-61 PHOTO REFLECTOR NJL5197K-W-F20 (TE1)
< TRANSISTOR >
Q302 8-729-426-36 TRANSISTOR XP1215-TXE
Q304 8-729-426-36 TRANSISTOR XP1215-TXE
Q305 8-729-038-06 FET HN1K02FU (TE85L)
Q306 8-729-037-63 TRANSISTOR UN9115J- (TX).SO
Q309 8-729-053-70 TRANSISTOR 2SA202800LS0
Q311 8-729-038-06 FET HN1K02FU (TE85L)
Q312 8-729-230-63 TRANSISTOR 2SD1819A-QRS-TX
Q314 8-729-230-63 TRANSISTOR 2SD1819A-QRS-TX
Q315 8-729-038-06 FET HN1K02FU (TE85L)
Q316 8-729-046-89 TRANSISTOR 2SB970-S (TX).S0
Q317 8-729-426-36 TRANSISTOR XP1215-TXE
Q602 8-729-420-24 TRANSISTOR 2SB1218A-QRS-TX
Q603 8-729-039-36 TRANSISTOR MDC06TR
Q701 8-729-046-89 TRANSISTOR 2SB970-S (TX).S0
Q704 8-729-420-50 TRANSISTOR UN5215- (TX)
< RESISTOR >
R101 1-218-967-11 RES-CHIP 15K 5% 1/16W
R102 1-218-943-11 RES-CHIP 150 5% 1/16W
R103 1-218-977-11 RES-CHIP 100K 5% 1/16W
R104 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R105 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R107 1-218-953-11 RES-CHIP 1K 5% 1/16W
R108 1-218-969-11 RES-CHIP 22K 5% 1/16W
R109 1-244-161-11 RES-CHIP 2.2 5% 1/16W
R111 1-218-953-11 RES-CHIP 1K 5% 1/16W
(EXCEPT FR)
R111 1-218-967-11 RES-CHIP 15K 5% 1/16W
(FR)
R112 1-218-973-11 RES-CHIP 47K 5% 1/16W
R113 1-218-953-11 RES-CHIP 1K 5% 1/16W
(EXCEPT FR)
R113 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
(FR)
R114 1-218-989-11 RES-CHIP 1M 5% 1/16W
R115 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
(EXCEPT FR)
R115 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
(FR)
R116 1-218-973-11 RES-CHIP 47K 5% 1/16W
R117 1-208-675-11 METAL CHIP 470 0.5% 1/16W
R150 1-218-941-11 RES-CHIP 100 5% 1/16W
(FR)
R201 1-218-967-11 RES-CHIP 15K 5% 1/16W
R202 1-218-943-11 RES-CHIP 150 5% 1/16W
R203 1-218-977-11 RES-CHIP 100K 5% 1/16W
R204 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R205 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R207 1-218-953-11 RES-CHIP 1K 5% 1/16W
R208 1-218-969-11 RES-CHIP 22K 5% 1/16W
R209 1-244-161-11 RES-CHIP 2.2 5% 1/16W
R211 1-218-953-11 RES-CHIP 1K 5% 1/16W
(EXCEPT FR)
R211 1-218-967-11 RES-CHIP 15K 5% 1/16W
(FR)
R212 1-218-973-11 RES-CHIP 47K 5% 1/16W
R213 1-218-953-11 RES-CHIP 1K 5% 1/16W
(EXCEPT FR)
R213 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
(FR)
R214 1-218-989-11 RES-CHIP 1M 5% 1/16W
R215 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
(EXCEPT FR)
R215 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
(FR)
R216 1-218-973-11 RES-CHIP 47K 5% 1/16W
R217 1-208-675-11 METAL CHIP 470 0.5% 1/16W
R250 1-218-941-11 RES-CHIP 100 5% 1/16W
(FR)
R301 1-218-981-11 RES-CHIP 220K 5% 1/16W
R302 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R303 1-218-985-11 RES-CHIP 470K 5% 1/16W
R305 1-218-985-11 RES-CHIP 470K 5% 1/16W
R306 1-218-989-11 RES-CHIP 1M 5% 1/16W
R308 1-220-803-11 RES-CHIP 4.7 5% 1/16W
R309 1-218-971-11 RES-CHIP 33K 5% 1/16W
R310 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R312 1-218-969-11 RES-CHIP 22K 5% 1/16W
R313 1-208-939-11 METAL CHIP 150K 0.5% 1/16W
R314 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R316 1-218-985-11 RES-CHIP 470K 5% 1/16W
R317 1-218-985-11 RES-CHIP 470K 5% 1/16W
R318 1-218-941-11 RES-CHIP 100 5% 1/16W
R319 1-218-969-11 RES-CHIP 22K 5% 1/16W
R320 1-218-985-11 RES-CHIP 470K 5% 1/16W
R600 1-218-969-11 RES-CHIP 22K 5% 1/16W
R601 1-218-973-11 RES-CHIP 47K 5% 1/16W
R602 1-218-973-11 RES-CHIP 47K 5% 1/16W
R603 1-218-969-11 RES-CHIP 22K 5% 1/16W
R604 1-218-977-11 RES-CHIP 100K 5% 1/16W
R605 1-218-985-11 RES-CHIP 470K 5% 1/16W
R606 1-218-981-11 RES-CHIP 220K 5% 1/16W
R607 1-218-985-11 RES-CHIP 470K 5% 1/16W
R608 1-218-977-11 RES-CHIP 100K 5% 1/16W
R609 1-218-965-11 RES-CHIP 10K 5% 1/16W
R610 1-218-977-11 RES-CHIP 100K 5% 1/16W
MAIN
