Sony WM-EX921 Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
29
WM-EX921
R611 1-218-983-11 RES-CHIP 330K 5% 1/16W
R612 1-218-989-11 RES-CHIP 1M 5% 1/16W
R613 1-218-989-11 RES-CHIP 1M 5% 1/16W
R614 1-218-977-11 RES-CHIP 100K 5% 1/16W
R615 1-218-981-11 RES-CHIP 220K 5% 1/16W
R701 1-218-937-11 RES-CHIP 47 5% 1/16W
R702 1-218-941-11 RES-CHIP 100 5% 1/16W
R705 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R706 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R707 1-208-943-11 METAL CHIP 220K 0.5% 1/16W
R708 1-218-985-11 RES-CHIP 470K 5% 1/16W
R709 1-218-977-11 RES-CHIP 100K 5% 1/16W
R710 1-218-985-11 RES-CHIP 470K 5% 1/16W
R711 1-218-973-11 RES-CHIP 47K 5% 1/16W
R712 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R713 1-218-987-11 RES-CHIP 680K 5% 1/16W
R716 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R717 1-208-707-11 METAL CHIP 10K 0.5% 1/16W
R718 1-208-675-11 METAL CHIP 470 0.5% 1/16W
R719 1-208-687-11 METAL CHIP 1.5K 0.5% 1/16W
R720 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R721 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R722 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R723 1-208-703-11 METAL CHIP 6.8K 0.5% 1/16W
R724 1-208-687-11 METAL CHIP 1.5K 0.5% 1/16W
R725 1-218-953-11 RES-CHIP 1K 5% 1/16W
R727 1-218-985-11 RES-CHIP 470K 5% 1/16W
R728 1-218-985-11 RES-CHIP 470K 5% 1/16W
R729 1-218-985-11 RES-CHIP 470K 5% 1/16W
R731 1-218-989-11 METAL CHIP 1M 0.5% 1/16W
R732 1-218-985-11 METAL CHIP 470K 0.5% 1/16W
R733 1-218-985-11 METAL CHIP 470K 0.5% 1/16W
R734 1-218-985-11 METAL CHIP 470K 0.5% 1/16W
R735 1-208-943-11 METAL CHIP 220K 0.5% 1/16W
R736 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R737 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
< VARIABLE RESISTOR >
RV601 1-223-325-21 RES, ADJ, METAL GLAZE 100K
< SWITCH >
S301 1-692-605-11 SWITCH, SLIDE (VOL, AVLS)
S702 1-771-475-21 SWITCH, SLIDE (DIRECTION)
S703 1-771-816-21 SWITCH, LEVER (SLIDE) (JOG LEVER)
< VIBRATOR >
X701 1-767-386-21 VIBRATOR, CRYSTAL (32.768kHz)
***********************************************************
MISCELLANEOUS
**************
HP901 1-500-639-22 HEAD, MAGNETIC (PLAYBACK)
M601 1-763-559-12 MOTOR, DC (CAPSTAN/REEL) (WITH PULLEY)
PM701 1-454-674-32 SOLENOID, PLUNGER
S704 1-762-553-11 SWITCH, LEAF (TAPE DETECT, ATS)
************************************************************
ACCESSORIES
************
0 1-475-622-21 ADAPTOR, AC (AC-E455) (CH)
0 1-476-716-11 ADAPTOR, AC (AC-E455) (JE)
0 1-476-739-11 ADAPTOR, AC (AC-E455) (KR)
0 1-476-845-11 ADAPTOR, AC (AC-ES455) (AEP, EE, FR)
0 1-569-007-11 ADAPTOR, CONVERSION 2P (JE)
1-756-036-11 BATTERY, NICKEL HYDROGEN (EXCEPT JE)
1-756-120-12 BATTERY, NICKEL HYDROGEN (JE)
0 1-756-231-11 STAND, CHARGER
3-008-521-01 CASE, BATTERY CHARGE
3-220-749-01 CASE, CARRYING
3-234-048-01 MANUAL, INSTRUCTION (JAPANESE) (JE)
3-234-048-11 MANUAL, INSTRUCTION (ENGLISH,
SIMPLIFIED CHINESE, KOREAN) (CH, JE, KR)
3-234-048-21 MANUAL, INSTRUCTION (ENGLISH, FRENCH,
GERMAN) (AEP, FR)
3-234-048-31 MANUAL, INSTRUCTION (SPANISH,
PORTUGUESE, ITALIAN) (AEP)
3-234-048-41 MANUAL, INSTRUCTION (DUTCH, SWEDISH,
FINNISH) (AEP)
3-234-048-51 MANUAL, INSTRUCTION (ENGLISH, POLISH,
RUSSIAN) (EE)
3-234-048-61 MANUAL, INSTRUCTION (HUNGARIAN,
CZECH, SLOVAKIAN) (EE)
8-953-811-91 RECEIVER, EAR MDR-E803SP
A-3052-977-A REMOTE CONTROL ASSY (RMWME23RL)
MAIN
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
