Sony WM-FX271

– 22 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
C326 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C327 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C332 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C333 1-126-162-11 ELECT 3.3uF 20% 50V
C334 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C335 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
C336 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C337 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C338 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C601 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C602 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C603 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C604 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C605 1-135-149-21 TANTALUM CHIP 2.2uF 20% 10V
C606 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C608 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C701 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C702 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C703 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C705 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C706 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C707 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C708 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C709 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C710 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C711 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C712 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C714 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C715 1-164-360-11 CERAMIC CHIP 0.1uF 16V
< FILTER >
CF1 1-760-345-21 FILTER, CERAMIC
CF2 1-781-137-11 FILTER ASSY, CERAMIC
< CONNECTOR >
CN301 1-750-346-21 CONNECTOR, FFC/EPC (ZIF) 6P
< BPF >
CP1 1-236-711-21 FILTER, BAND PASS (EXCEPT EE)
CP1 1-239-813-21 FILTER, BAND PASS (EE)
< TRIMMER >
CT1 1-141-422-11 CAP, ADJ 10PF
< DIODE >
D1 8-719-049-75 DIODE KV1520TL00
D2 8-719-053-30 DIODE MA2S357-(TX).SO
D3 8-719-053-30 DIODE MA2S357-(TX).SO
D301 8-719-049-09 DIODE 1SS367-T3SONY
D302 8-719-801-78 DIODE 1SS184
D303 8-719-801-78 DIODE 1SS184
D701 8-719-400-20 DIODE MA152WA
< IC >
IC1 8-759-493-20 IC A2111F-(EL)
IC301 8-759-574-69 IC LB8115W-TLM
IC701 8-759-574-71 IC uPD17072GB-559-1A7
IC702 8-759-469-63 IC S-81215SGUP-DQK-T1
< JACK >
J301 1-565-287-11 JACK (2)
J302 1-750-061-11 JACK, DC (POLARITY UNIFIED TYPE)
(DC IN 3V)
< JUMPER RESISTOR >
JR2 1-216-864-11 METAL CHIP 0 5% 1/16W
(US,CND,C&SA)
JR4 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT US,CND,C&SA)
JR5 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT US,CND,C&SA)
JR14 1-216-793-11 RES,CHIP 4.7 5% 1/16W
(US,CND)
JR14 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT US,CND)
JR301 1-216-296-00 SHORT 0
JR701 1-216-864-11 METAL CHIP 0 5% 1/16W
(EE,E,9E)
JR702 1-216-864-11 METAL CHIP 0 5% 1/16W
(AEP,2AEP,FR,CEV,CH)
JR704 1-216-864-11 METAL CHIP 0 5% 1/16W
JR706 1-216-864-11 METAL CHIP 0 5% 1/16W
JR707 1-216-864-11 METAL CHIP 0 5% 1/16W
< COIL >
L2 1-416-528-11 COIL, AIR-CORE (EXCEPT EE)
L2 1-416-967-11 COIL, AIR-CORE (EE)
L3 1-416-449-11 COIL, AIR-CORE (EXCEPT EE)
L3 1-416-968-11 COIL, AIR-CORE (EE)
L4 1-416-423-11 COIL(WITH CORE) (AM OSC)
L101 1-414-760-21 INDUCTOR, FERRITE BEAD
L201 1-414-760-21 INDUCTOR, FERRITE BEAD
L301 1-414-235-22 INDUCTOR, FERRITE BEAD
L302 1-414-760-21 INDUCTOR, FERRITE BEAD
L304 1-414-760-21 INDUCTOR, FERRITE BEAD
L701 1-412-995-21 INDUCTOR 22uH
< TRANSISTOR >
Q2 8-729-102-27 TRANSISTOR 2SC2223-T1F12
Q101 8-729-424-67 TRANSISTOR UN2216
Q201 8-729-424-67 TRANSISTOR UN2216
Q301 8-729-216-22 TRANSISTOR 2SA1162-G
Q302 8-729-900-52 TRANSISTOR DTC114YK
Q303 8-729-402-13 TRANSISTOR XN1501
Q304 8-729-141-48 TRANSISTOR 2SB624-BV345
Q305 8-729-402-13 TRANSISTOR XN1501
