Sony WM-FX271

– 23 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
Q306 8-729-403-17 TRANSISTOR XN1215
Q307 8-729-422-27 TRANSISTOR 2SD601A-Q
Q308 8-729-900-52 TRANSISTOR DTC114YK
Q701 8-729-422-27 TRANSISTOR 2SD601A-Q
Q702 8-729-422-27 TRANSISTOR 2SD601A-Q
Q703 8-729-102-27 TRANSISTOR 2SC2223-T1F12
Q704 8-729-011-47 TRANSISTOR XN4311
< RESISTOR >
R1 1-216-851-11 METAL CHIP 330K 5% 1/16W
R2 1-216-839-11 METAL CHIP 33K 5% 1/16W
R3 1-216-851-11 METAL CHIP 330K 5% 1/16W
R4 1-216-837-11 METAL CHIP 22K 5% 1/16W
R5 1-216-847-11 METAL CHIP 150K 5% 1/16W
R6 1-216-851-11 METAL CHIP 330K 5% 1/16W
R7 1-216-847-11 METAL CHIP 150K 5% 1/16W
R8 1-216-851-11 METAL CHIP 330K 5% 1/16W
R9 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R10 1-216-809-11 METAL CHIP 100 5% 1/16W
R11 1-216-833-11 RES,CHIP 10K 5% 1/16W
R12 1-216-797-11 METAL CHIP 10 5% 1/16W
R13 1-216-821-11 METAL CHIP 1K 5% 1/16W
R14 1-216-815-11 METAL CHIP 330 5% 1/16W
R15 1-216-841-11 METAL CHIP 47K 5% 1/16W
(EXCEPT FR)
R15 1-216-842-11 METAL CHIP 56K 5% 1/16W
(FR)
R16 1-216-841-11 METAL CHIP 47K 5% 1/16W
(EXCEPT FR)
R16 1-216-842-11 METAL CHIP 56K 5% 1/16W
(FR)
R17 1-216-797-11 METAL CHIP 10 5% 1/16W
R18 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
(US,CND)
R18 1-216-835-11 METAL CHIP 15K 5% 1/16W
(EXCEPT US,CND)
R20 1-216-815-11 METAL CHIP 330 5% 1/16W
R21 1-216-864-11 METAL CHIP 0 5% 1/16W
R103 1-216-835-11 METAL CHIP 15K 5% 1/16W
R104 1-216-835-11 METAL CHIP 15K 5% 1/16W
R105 1-216-855-11 METAL CHIP 680K 5% 1/16W
R106 1-216-818-11 METAL CHIP 560 5% 1/16W
R107 1-216-795-11 RES,CHIP 6.8 5% 1/16W
(FX271:US,CND,2AEP)
R107 1-216-799-11 METAL CHIP 15 5% 1/16W
(FX271:EXCEPT US,CND,2AEP,FR/FX275)
R107 1-216-807-11 METAL CHIP 68 5% 1/16W
(FR)
R108 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R110 1-216-812-11 METAL CHIP 180 5% 1/16W
(EXCEPT US,CND,2AEP,FR)
R110 1-216-815-11 METAL CHIP 330 5% 1/16W
(US,CND,2AEP)
R110 1-216-816-11 METAL CHIP 390 5% 1/16W
(FR)
R111 1-216-821-11 METAL CHIP 1K 5% 1/16W
R112 1-216-821-11 METAL CHIP 1K 5% 1/16W
R203 1-216-835-11 METAL CHIP 15K 5% 1/16W
R204 1-216-835-11 METAL CHIP 15K 5% 1/16W
R205 1-216-855-11 METAL CHIP 680K 5% 1/16W
R206 1-216-818-11 METAL CHIP 560 5% 1/16W
R207 1-216-795-11 RES,CHIP 6.8 5% 1/16W
(FX271:US,CND,2AEP)
R207 1-216-799-11 METAL CHIP 15 5% 1/16W
(FX271:EXCEPT US,CND,2AEP,FR/FX275)
R207 1-216-807-11 METAL CHIP 68 5% 1/16W
(FR)
R208 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R210 1-216-812-11 METAL CHIP 180 5% 1/16W
(EXCEPT US,CND,2AEP,FR)
R210 1-216-815-11 METAL CHIP 330 5% 1/16W
(US,CND,2AEP)
R210 1-216-816-11 METAL CHIP 390 5% 1/16W
(FR)
R301 1-216-821-11 METAL CHIP 1K 5% 1/16W
R302 1-216-837-11 METAL CHIP 22K 5% 1/16W
R303 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R304 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R305 1-216-833-11 RES,CHIP 10K 5% 1/16W
R306 1-216-847-11 METAL CHIP 150K 5% 1/16W
R307 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R308 1-216-819-11 METAL CHIP 680 5% 1/16W
R309 1-216-845-11 METAL CHIP 100K 5% 1/16W
R310 1-216-864-11 METAL CHIP 0 5% 1/16W
R311 1-216-821-11 METAL CHIP 1K 5% 1/16W
R312 1-216-835-11 METAL CHIP 15K 5% 1/16W
R313 1-216-821-11 METAL CHIP 1K 5% 1/16W
R319 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R320 1-216-218-00 RES,CHIP 6.8K 5% 1/8W
R321 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R324 1-216-833-11 RES,CHIP 10K 5% 1/16W
R326 1-216-845-11 METAL CHIP 100K 5% 1/16W
R327 1-216-134-00 METAL CHIP 2.2 5% 1/8W
R328 1-216-839-11 METAL CHIP 33K 5% 1/16W
R329 1-216-864-11 METAL CHIP 0 5% 1/16W
R408 1-216-845-11 METAL CHIP 100K 5% 1/16W
R601 1-216-821-11 METAL CHIP 1K 5% 1/16W
R605 1-216-835-11 METAL CHIP 15K 5% 1/16W
R606 1-216-845-11 METAL CHIP 100K 5% 1/16W
R608 1-216-833-11 RES,CHIP 10K 5% 1/16W
R609 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R610 1-216-821-11 METAL CHIP 1K 5% 1/16W
R611 1-216-864-11 METAL CHIP 0 5% 1/16W
R701 1-216-842-11 METAL CHIP 56K 5% 1/16W
R702 1-216-845-11 METAL CHIP 100K 5% 1/16W
R703 1-216-815-11 METAL CHIP 330 5% 1/16W
R704 1-216-803-11 METAL CHIP 33 5% 1/16W
R706 1-216-833-11 RES,CHIP 10K 5% 1/16W
R707 1-216-833-11 RES,CHIP 10K 5% 1/16W
