Sony WM-FX271

– 24 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
R708 1-216-833-11 RES,CHIP 10K 5% 1/16W
R709 1-216-833-11 RES,CHIP 10K 5% 1/16W
R710 1-216-833-11 RES,CHIP 10K 5% 1/16W
R711 1-216-833-11 RES,CHIP 10K 5% 1/16W
R712 1-216-833-11 RES,CHIP 10K 5% 1/16W
R715 1-216-841-11 METAL CHIP 47K 5% 1/16W
R718 1-220-397-11 RES,CHIP 4.7M 5% 1/16W
R719 1-216-833-11 RES,CHIP 10K 5% 1/16W
R720 1-218-879-11 RES,CHIP 22K 0.50% 1/16W
R721 1-218-915-11 RES,CHIP 680K 0.50% 1/16W
R723 1-216-845-11 METAL CHIP 100K 5% 1/16W
R725 1-216-845-11 METAL CHIP 100K 5% 1/16W
< VARIABLE RESISTOR >
RV301 1-225-748-21 RES, VAR, CARBON 10K/10K (VOLUME)
RV601 1-241-784-11 RES, ADJ, CARBON 5K
< SWITCH >
S301 1-762-742-31 SWITCH, DETECTION (SMALL TYPE)
(TAPE POWER)
S303 1-692-298-11 SWITCH, SLIDE (NORM•CrO
2
/METAL,
DX•LOCAL) (US,CND,C&SA)
S303 1-692-298-11 SWITCH, SLIDE (NORM•CrO
2
/METAL,
ST•FM MONO) (EXCEPT US,CND,C&SA)
S305 1-692-298-11 SWITCH, SLIDE (AVLS)
S716 1-572-922-11 SWITCH, SLIDE (HOLD)
< TRANSFORMER >
T1 1-406-694-11 COIL, AM IFT
T301 1-426-917-11 TRANSFORMER, DC-DC CONVERTER
< THERMISTOR (POSITIVE) >
TH601 1-810-794-11 THERMISTOR, POSITIVE
< VIBRATOR >
X2 1-781-137-11 FILTER ASSY, CERAMIC
X701 1-577-262-11 VIBRATOR, CRYSTAL (75kHz)
*************************************************************
MISCELLANEOUS
***************
HP901 1-500-532-11 HEAD, MAGNETIC (PLAYBACK)
L1 1-501-961-11 ANTENNA, FERRITE-ROD (AM)
LCD701 1-803-305-11 DISPLAY PANEL, LIQUID CRYSTAL
M901 1-763-073-11 MOTOR (CAPSTAN/REEL) (including PULLEY)
*************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
1-505-521-11 HEADPHONE (MDR-023)
(FX271:US,CND,2AEP,FR)
3-032-906-01 CASE, CARRYING
3-864-879-11 MANUAL, INSTRUCTION (ENGLISH,FRENCH,
ITALIAN) (US,CND,AEP,2AEP,FR)
3-864-879-21 MANUAL, INSTRUCTION (SPANISH,
PORTUGUESE) (AEP,2AEP,C&SA)
3-864-879-31 MANUAL, INSTRUCTION (GERMAN,DUTCH,
SWEDISH,FINNISH) (AEP,2AEP)
3-864-879-41 MANUAL, INSTRUCTION (ENGLISH,HUNGARIAN,
BULGARIAN,RUSSIAN) (EE,CEV)
3-864-879-51 MANUAL, INSTRUCTION (POLISH,CZECH,
GREEK,TURKISH) (CEV)
3-864-879-61 MANUAL, INSTRUCTION (ENGLISH,
TRADITIONAL CHINESE,
KOREAN,ARABIC) (E)
3-864-879-71 MANUAL, INSTRUCTION (ENGLISH,
TRADITIONAL CHINESE,
KOREAN,ARABIC) (9E)
3-864-879-91 MANUAL, INSTRUCTION (SIMPLIFIED CHINESE,
ENGLISH) (CH)
8-953-130-90 HEADPHONE MDR-E805LP/K SET
(EXCEPT US,CND,2AEP,FR)
8-953-741-90 HEADPHONE, STEREO MDR-A0101LP (FX275)
Sony Corporation
Personal A&V Products Company
9-926-958-11
WM-FX271/FX275
99B0482-1
Printed in Japan C1999. 2
Published by Quality Engineering Dept.
(Shinagawa)
