Sony XR-CA310 - Heat Sink; Motor (Capstan;Reel) (M901)

XR-CA310/L210
11
2-6. HEAT SINK
2-7. MOTOR (CAPSTAN/REEL) (M901)
1 five screws
(PTT2.6 × 10)
1 two screws
(PTT2.6 × 10)
(XR-CA310)
2 heat sink
1 two screws
(P2
× 2.5)
4 motor (capstan/reel)
(M901)
3 sub belt (C)
2 main belt
Note : When installing motor,
adjust the screw and
screw hole of motor.
