SECTION 2
DISASSEMBLY
• This set can be disassembled in the order shown below.
2-1. DISASSEMBLY FLOW
SET
2-2. SUB PANEL
(Page 9)
2-3. MECHANISM DECK
(MG-36SZ11-32)
(Page 9)
2-4. MAIN BOARD
(Page 10)
2-6. HEAT SINK
(Page 11)
2-5. BRACKET (MD)
(Page 10)
2-7. MOTOR
(CAPSTAN/REEL)
(M901)
(Page 11)
2-8. HEAD (PLAY BACK)
(HP901)
(Page 12)
2-9. MAIN BELT,
SUB BELT (C)
(Page 13)
