31
XR-CA310/L210
SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
CONTROL
CONTROL BOARD
**************
1-694-696-31 CONDUCTIVE BOARD, CONNECTION
1-786-098-11 SWITCH, SHEET
* 3-224-924-01 HOLDER (LCD)
* 3-224-925-01 PLATE, LIGHT GUIDE
* 3-224-926-01 ILLUMINATOR
* 3-224-927-01 PLATE (LCD), GROUND
< CAPACITOR >
C952 1-115-412-11 CERAMIC CHIP 680PF 5% 25V
C953 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C954 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C955 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
< CONNECTOR >
CN900 1-794-312-11 PIN, CONNECTOR 12P
< DIODE >
D900 8-719-056-82 DIODE UDZ-TE-17-6.2B
D901 8-719-056-82 DIODE UDZ-TE-17-6.2B
D903 8-719-056-82 DIODE UDZ-TE-17-6.2B
D904 8-719-056-82 DIODE UDZ-TE-17-6.2B
D905 8-719-056-82 DIODE UDZ-TE-17-6.2B
D910 8-719-033-13 LED CL-170Y-CD-T
(CA310: 2, DISC +/L210: 2) (AMBER)
D910 8-719-082-98 LED CL-170FG-CD-T
(CA310: 2, DISC +/L210: 2) (GREEN)
D911 8-719-033-13 LED CL-170Y-CD-T (CA310: 3, REP/L210: 3)
(AMBER)
D911 8-719-082-98 LED CL-170FG-CD-T (CA310: 3, REP/L210: 3)
(GREEN)
D912 8-719-033-13 LED CL-170Y-CD-T (CA310: 4, SHUF/L210: 4)
(AMBER)
D912 8-719-082-98 LED CL-170FG-CD-T
(CA310: 4, SHUF/L210: 4) (GREEN)
D913 8-719-033-13 LED CL-170Y-CD-T (5) (AMBER)
D913 8-719-082-98 LED CL-170FG-CD-T (5) (GREEN)
D914 8-719-033-13 LED CL-170Y-CD-T (ATT) (AMBER)
D914 8-719-082-98 LED CL-170FG-CD-T (ATT) (GREEN)
D915 8-719-033-13 LED CL-170Y-CD-T (SENS, BTM) (AMBER)
D915 8-719-082-98 LED CL-170FG-CD-T (SENS, BTM) (GREEN)
D916 8-719-033-13 LED CL-170Y-CD-T (AF) (AMBER)
D916 8-719-082-98 LED CL-170FG-CD-T (AF) (GREEN)
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Abbreviation
AMBER : Amber illumination type
GREEN : Green illumination type
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
When indicating parts by reference
number, please include the board.
D917 8-719-033-13 LED CL-170Y-CD-T
(CA310: 1, DISC -/L210: 1) (AMBER)
D917 8-719-082-98 LED CL-170FG-CD-T
(CA310: 1, DISC -/L210: 1) (GREEN)
D918 8-719-033-86 LED CL-170D-CD-T (ILLUMINATION)
(GREEN)
D918 8-719-082-98 LED CL-170FG-CD-T (ILLUMINATION)
(AMBER)
D920 8-719-082-71 LED LOT676-RS (ILLUMINATION) (AMBER)
D920 8-719-084-33 LED LTT673-Q2R1R2 (ILLUMINATION)
(GREEN)
D921 8-719-082-71 LED LOT676-RS (ILLUMINATION) (AMBER)
D921 8-719-084-33 LED LTT673-Q2R1R2 (ILLUMINATION)
(GREEN)
D922 8-719-033-13 LED CL-170Y-CD-T (6, ATA) (AMBER)
D922 8-719-082-98 LED CL-170FG-CD-T (6, ATA) (GREEN)
D923 8-719-033-13 LED CL-170Y-CD-T (TA) (AMBER)
D923 8-719-082-98 LED CL-170FG-CD-T (TA) (GREEN)
D924 8-719-033-13 LED CL-170Y-CD-T (PTY) (AMBER)
D924 8-719-082-98 LED CL-170FG-CD-T (PTY) (GREEN)
D925 8-719-033-13 LED CL-170Y-CD-T (DSPL) (AMBER)
D925 8-719-082-98 LED CL-170FG-CD-T (DSPL) (GREEN)
D960 8-719-988-61 DIODE 1SS355TE-17
D961 8-719-988-61 DIODE 1SS355TE-17
D962 8-719-988-61 DIODE 1SS355TE-17
D963 8-719-988-61 DIODE 1SS355TE-17
D964 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC900 8-759-657-06 IC LC75884W
< LIQUID CRYSTAL DISPLAY >
LCD900 1-804-512-11 DISPLAY PANEL, LIQUID CRYSTAL
< PILOT LAMP >
PL901 1-518-743-21 LAMP, PILOT (LCD BACK LIGHT) (AMBER)
PL901 1-518-743-31 LAMP, PILOT (LCD BACK LIGHT) (GREEN)
PL902 1-518-743-21 LAMP, PILOT (LCD BACK LIGHT) (AMBER)
PL902 1-518-743-31 LAMP, PILOT (LCD BACK LIGHT) (GREEN)
< RESISTOR >
R900 1-216-295-11 SHORT 0
R901 1-216-049-11 RES-CHIP 1K 5% 1/10W
R902 1-216-049-11 RES-CHIP 1K 5% 1/10W
Ver 1.2 2001.05
