Sony XR-CA310 - Page 32

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
32
XR-CA310/L210
R903 1-216-049-11 RES-CHIP 1K 5% 1/10W
R904 1-216-049-11 RES-CHIP 1K 5% 1/10W
R905 1-216-049-11 RES-CHIP 1K 5% 1/10W
R910 1-216-025-11 RES-CHIP 100 5% 1/10W
(GREEN)
R910 1-216-027-00 METAL CHIP 120 5% 1/10W
(AMBER)
R911 1-216-023-00 METAL CHIP 82 5% 1/10W
(GREEN)
R911 1-216-027-00 METAL CHIP 120 5% 1/10W
(AMBER)
R912 1-216-025-11 RES-CHIP 100 5% 1/10W
(GREEN)
R912 1-216-027-00 METAL CHIP 120 5% 1/10W
(AMBER)
R913 1-216-023-00 METAL CHIP 82 5% 1/10W
(GREEN)
R913 1-216-027-00 METAL CHIP 120 5% 1/10W
(AMBER)
R914 1-216-029-00 METAL CHIP 150 5% 1/10W
R915 1-216-029-00 METAL CHIP 150 5% 1/10W
R916 1-216-029-00 METAL CHIP 150 5% 1/10W
R917 1-216-025-11 RES-CHIP 100 5% 1/10W
(GREEN)
R917 1-216-029-00 METAL CHIP 150 5% 1/10W
(AMBER)
R918 1-216-025-11 RES-CHIP 100 5% 1/10W
(GREEN)
R918 1-216-029-00 METAL CHIP 150 5% 1/10W
(AMBER)
R919 1-216-027-00 METAL CHIP 120 5% 1/10W
R920 1-216-025-11 RES-CHIP 100 5% 1/10W
(GREEN)
R920 1-216-027-00 METAL CHIP 120 5% 1/10W
(AMBER)
R921 1-216-023-00 METAL CHIP 82 5% 1/10W
(GREEN)
R921 1-216-027-00 METAL CHIP 120 5% 1/10W
(AMBER)
R922 1-216-045-00 METAL CHIP 680 5% 1/10W
(GREEN)
R922 1-216-047-00 RES-CHIP 820 5% 1/10W
(AMBER)
R954 1-216-088-00 METAL CHIP 43K 5% 1/10W
R955 1-216-295-11 SHORT 0
**************************************************************
* A-3274-179-A MAIN BOARD, COMPLETE (L210: AMBER)
* A-3326-857-A MAIN BOARD, COMPLETE (CA310: AMBER)
* A-3326-990-A MAIN BOARD, COMPLETE (CA310: GREEN)
* A-3340-001-A MAIN BOARD, COMPLETE (L210: GREEN)
*********************
* 3-041-578-01 BRACKET (IC)
* 3-224-921-01 HEAT SINK
7-685-794-09 SCREW +PTT 2.6X10 (S)
< JACK >
ANT100 1-815-185-11 JACK (ANT) (FM/AM ANTENNA)
< CAPACITOR/SHORT >
C1 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C2 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C3 1-164-160-11 CERAMIC CHIP 20PF 5% 50V
C4 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C5 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C7 1-124-234-00 ELECT 22uF 20% 16V
C8 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C21 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C22 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C81 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C82 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C101 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C102 1-124-584-00 ELECT 100uF 20% 10V
C103 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C104 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C109 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C124 1-124-257-00 ELECT 2.2uF 20% 50V
C125 1-124-257-00 ELECT 2.2uF 20% 50V
C130 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C131 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C150 1-124-257-00 ELECT 2.2uF 20% 50V
C160 1-124-257-00 ELECT 2.2uF 20% 50V
C161 1-124-257-00 ELECT 2.2uF 20% 50V
C162 1-104-942-11 ELECT 1uF 20% 50V
(CA310)
C163 1-104-942-11 ELECT 1uF 20% 50V
(CA310)
C164 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C165 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C200 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C201 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C202 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C203 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C204 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C205 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C208 1-124-589-11 ELECT 47uF 20% 16V
C209 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C211 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C212 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C213 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C214 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C250 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C251 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C252 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C253 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C254 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C255 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C256 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C257 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C258 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C290 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C291 1-124-234-00 ELECT 22uF 20% 16V
C350 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C351 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C352 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C353 1-124-234-00 ELECT 22uF 20% 16V
C354 1-124-584-00 ELECT 100uF 20% 10V
C355 1-124-584-00 ELECT 100uF 20% 10V
C356 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
CONTROL MAIN
