Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
33
XR-CA310/L210
MAIN
C357 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C358 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C359 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C360 1-124-584-00 ELECT 100uF 20% 10V
C361 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C362 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C363 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C400 1-124-234-00 ELECT 22uF 20% 16V
C401 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C402 1-124-589-11 ELECT 47uF 20% 16V
C403 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C410 1-104-942-11 ELECT 1uF 20% 50V
C411 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C412 1-124-257-00 ELECT 2.2uF 20% 50V
C413 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C414 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C415 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C416 1-104-942-11 ELECT 1uF 20% 50V
C420 1-104-942-11 ELECT 1uF 20% 50V
C421 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C422 1-124-257-00 ELECT 2.2uF 20% 50V
C423 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C424 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C425 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C426 1-104-942-11 ELECT 1uF 20% 50V
C430 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(CA310)
C431 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(CA310)
C450 1-124-257-00 ELECT 2.2uF 20% 50V
C451 1-124-257-00 ELECT 2.2uF 20% 50V
C452 1-124-257-00 ELECT 2.2uF 20% 50V
C453 1-124-257-00 ELECT 2.2uF 20% 50V
C454 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C456 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C458 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C460 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C464 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C465 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C466 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C467 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C500 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C501 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C502 1-126-157-11 ELECT 10uF 20% 16V
C503 1-126-157-11 ELECT 10uF 20% 16V
C504 1-216-864-11 SHORT 0
C506 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C507 1-126-157-11 ELECT 10uF 20% 16V
C620 1-124-589-11 ELECT 47uF 20% 16V
C621 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C622 1-124-257-00 ELECT 2.2uF 20% 50V
C640 1-104-942-11 ELECT 1uF 20% 50V
C700 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C702 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C710 1-126-936-11 ELECT 3300uF 20% 16V
C720 1-104-942-11 ELECT 1uF 20% 50V
C721 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C722 1-126-162-11 ELECT 3.3uF 20% 50V
C730 1-126-157-11 ELECT 10uF 20% 16V
C731 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C732 1-124-584-00 ELECT 100uF 20% 10V
C733 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C734 1-124-234-00 ELECT 22uF 20% 16V
C740 1-126-157-11 ELECT 10uF 20% 16V
C741 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C742 1-124-584-00 ELECT 100uF 20% 10V
C743 1-125-701-11 DOUBLE LAYER 0.047F 5.5V
C750 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C800 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(CA310)
C801 1-126-940-11 ELECT 330uF 20% 16V
(CA310)
< CONNECTOR >
* CN300 1-564-705-11 PIN, CONNECTOR (PC BOARD) 3P
* CN350 1-573-486-11 PIN, CONNECTOR (PC BOARD) 8P
CN400 1-774-698-11 JACK, PIN 2P (BUS AUDIO IN) (CA310)
CN600 1-794-311-21 PLUG, CONNECTOR 12P
CN700 1-774-701-11 PIN, CONNECTOR 16P (POWER)
CN800 1-580-907-31 PLUG, CONNECTOR (BUS CONTROL IN)
(CA310)
< DISCHARGE GAP >
CP100 1-519-504-11 GAP, DISCHARGE
< DIODE >
D150 8-719-109-93 DIODE RD6.2ESB2
D250 8-719-109-93 DIODE RD6.2ESB2
D251 8-719-988-61 DIODE 1SS355TE-17
D252 8-719-988-61 DIODE 1SS355TE-17
D290 8-719-109-89 DIODE RD5.6ESB2
D351 8-719-988-61 DIODE 1SS355TE-17
D450 8-719-109-72 DIODE RD3.9ESB2
D500 8-719-079-42 DIODE 1ZB22 (TPA3)
D501 8-719-079-42 DIODE 1ZB22 (TPA3)
D502 8-719-079-42 DIODE 1ZB22 (TPA3)
D503 8-719-079-42 DIODE 1ZB22 (TPA3)
D504 8-719-079-42 DIODE 1ZB22 (TPA3)
D505 8-719-079-42 DIODE 1ZB22 (TPA3)
D506 8-719-079-42 DIODE 1ZB22 (TPA3)
D507 8-719-079-42 DIODE 1ZB22 (TPA3)
D620 8-719-110-03 DIODE RD7.5ESB2
D622 8-719-991-33 DIODE 1SS133T-77
D630 8-719-110-49 DIODE RD18ESB2 (CA310: GREEN)
D640 8-719-110-49 DIODE RD18ESB2
D650 8-719-110-49 DIODE RD18ESB2
D651 8-719-110-03 DIODE RD7.5ESB2 (L210)
D700 8-719-200-82 DIODE 11ES2
D710 8-719-049-38 DIODE 1N5404TU
D720 8-719-988-61 DIODE 1SS355TE-17
D721 8-719-200-82 DIODE 11ES2
D722 8-719-200-82 DIODE 11ES2
D731 8-719-110-14 DIODE RD9.1ESB3
D740 8-719-200-82 DIODE 11ES2
D741 8-719-935-40 DIODE HZS6B2LTD
D750 8-719-988-61 DIODE 1SS355TE-17
