Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
34
XR-CA310/L210
D800 8-719-109-93 DIODE RD6.2ESB2 (CA310)
D801 8-719-110-49 DIODE RD18ESB2 (CA310)
D802 8-719-110-49 DIODE RD18ESB2 (CA310)
D805 8-719-109-97 DIODE RD6.8ESB2 (CA310)
< IC >
IC1 8-759-982-77 IC MN101C49KTL
IC2 8-759-682-69 IC XC61AN4302MR
IC200 8-759-492-59 IC SAA6588T-118
IC250 8-759-909-71 IC BA4558F
IC350 8-759-924-46 IC BA4560F-T1
IC400 8-759-827-11 IC LC75421M-TLM
IC500 8-759-699-07 IC TA8263AH
IC800 8-759-096-16 IC MM1175XFF (CA310)
< COIL/SHORT >
L1 1-410-509-11 INDUCTOR 10uH
L100 1-410-322-11 INDUCTOR 3.3uH
L101 1-216-864-11 SHORT 0
L710 1-419-476-11 CHOKE COIL 250uH
< TRANSISTOR >
Q120 8-729-920-21 TRANSISTOR DTC314TKH04
Q121 8-729-920-21 TRANSISTOR DTC314TKH04
Q130 8-729-920-21 TRANSISTOR DTC314TKH04
Q150 8-729-043-32 TRANSISTOR PDTA114EK-115
Q151 8-729-043-27 TRANSISTOR PDTC114EK-115
Q250 8-729-043-27 TRANSISTOR PDTC114EK-115
Q290 8-729-205-96 TRANSISTOR 2SC3668-O
Q291 8-729-043-32 TRANSISTOR PDTA114EK-115
Q292 8-729-043-27 TRANSISTOR PDTC114EK-115
Q450 8-729-920-21 TRANSISTOR DTC314TKH04
Q451 8-729-920-21 TRANSISTOR DTC314TKH04
Q452 8-729-920-21 TRANSISTOR DTC314TKH04
Q453 8-729-920-21 TRANSISTOR DTC314TKH04
Q620 8-729-043-32 TRANSISTOR PDTA114EK-115
Q621 8-729-043-29 TRANSISTOR PDTC144EK-115
Q630 8-729-422-33 TRANSISTOR 2SD601A-Q-TX
(CA310: GREEN)
Q640 8-729-422-33 TRANSISTOR 2SD601A-Q-TX
Q650 8-729-043-27 TRANSISTOR PDTC114EK-115
Q651 8-729-422-33 TRANSISTOR 2SD601A-Q-TX (L210)
Q652 8-729-043-29 TRANSISTOR PDTC144EK-115 (L210)
Q700 8-729-205-95 TRANSISTOR 2SA1428-Y
Q702 8-729-043-27 TRANSISTOR PDTC114EK-115
Q703 8-729-205-95 TRANSISTOR 2SA1428-Y
Q704 8-729-043-27 TRANSISTOR PDTC114EK-115
Q720 8-729-043-33 TRANSISTOR PDTA124EK-115
Q721 8-729-216-22 TRANSISTOR 2SA1162-G
Q722 8-729-205-95 TRANSISTOR 2SA1428-Y
Q725 8-729-043-27 TRANSISTOR PDTC114EK-115
Q730 8-729-422-33 TRANSISTOR 2SD601A-Q-TX
Q731 8-729-216-22 TRANSISTOR 2SA1162-G
Q732 8-729-043-27 TRANSISTOR PDTC114EK-115
Q733 8-729-904-60 TRANSISTOR DTB113ZK
Q734 8-729-422-33 TRANSISTOR 2SD601A-Q-TX
Q740 8-729-205-95 TRANSISTOR 2SA1428-Y
Q741 8-729-422-33 TRANSISTOR 2SD601A-Q-TX
Q750 8-729-216-22 TRANSISTOR 2SA1162-G
< RESISTOR/DIODE/CAPACITOR >
R3 1-216-813-11 METAL CHIP 220 5% 1/16W
R4 1-216-864-11 SHORT 0
R7 1-216-809-11 METAL CHIP 100 5% 1/16W
R8 1-216-845-11 METAL CHIP 100K 5% 1/16W
R9 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R10 1-216-864-11 SHORT 0
R11 1-216-809-11 METAL CHIP 100 5% 1/16W
R12 1-216-809-11 METAL CHIP 100 5% 1/16W
R21 1-247-807-31 CARBON 100 5% 1/4W
R22 1-216-864-11 SHORT 0
R26 1-249-441-11 CARBON 100K 5% 1/4W
R27 1-216-841-11 METAL CHIP 47K 5% 1/16W
R28 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R29 1-216-809-11 METAL CHIP 100 5% 1/16W
R30 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R31 1-216-809-11 METAL CHIP 100 5% 1/16W
R32 1-247-807-31 CARBON 100 5% 1/4W
R33 1-247-807-31 CARBON 100 5% 1/4W
R34 1-247-807-31 CARBON 100 5% 1/4W
R41 1-216-809-11 METAL CHIP 100 5% 1/16W
R43 1-247-807-31 CARBON 100 5% 1/4W
R61 1-216-845-11 METAL CHIP 100K 5% 1/16W
R62 1-216-864-11 SHORT 0
R65 1-216-845-11 METAL CHIP 100K 5% 1/16W
R68 1-216-864-11 SHORT 0
R69 1-216-845-11 METAL CHIP 100K 5% 1/16W
R70 1-216-864-11 SHORT 0
R71 1-216-845-11 METAL CHIP 100K 5% 1/16W
R72 1-216-845-11 METAL CHIP 100K 5% 1/16W
R73 1-216-845-11 METAL CHIP 100K 5% 1/16W
R74 1-216-864-11 SHORT 0
R75 1-216-864-11 SHORT 0 (GREEN)
R76 1-216-845-11 METAL CHIP 100K 5% 1/16W
(AMBER)
R81 1-216-845-11 METAL CHIP 100K 5% 1/16W
R102 1-249-417-11 CARBON 1K 5% 1/4W
R103 1-216-841-11 METAL CHIP 47K 5% 1/16W
R104 1-247-807-31 CARBON 100 5% 1/4W
R105 1-247-807-31 CARBON 100 5% 1/4W
R106 1-247-807-31 CARBON 100 5% 1/4W
R107 1-247-807-31 CARBON 100 5% 1/4W
R108 1-216-845-11 METAL CHIP 100K 5% 1/16W
R115 1-216-864-11 SHORT 0
R118 1-216-849-11 METAL CHIP 220K 5% 1/16W
R120 1-216-837-11 METAL CHIP 22K 5% 1/16W
R121 1-216-837-11 METAL CHIP 22K 5% 1/16W
R122 1-216-839-11 METAL CHIP 33K 5% 1/16W
R123 1-216-839-11 METAL CHIP 33K 5% 1/16W
R130 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R131 1-216-073-00 METAL CHIP 10K 5% 1/10W
R150 1-216-819-11 METAL CHIP 680 5% 1/16W
R152 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R200 1-216-853-11 METAL CHIP 470K 5% 1/16W
R201 1-216-821-11 METAL CHIP 1K 5% 1/16W
MAIN
