20
XR-CA310/L210
• Waveforms
– MAIN Board –
1 IC200 4 (OSCO) 4 IC900 ud (OSC)
2 IC1 qs (OSC2)
3 IC1 qh (XO)
2.4 Vp-p
231 ns
1.8 Vp-p
54.3 ns
5.4 Vp-p
30.5 µs
– CONTROL Board –
2.6 Vp-p
21 µs
