Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
36
XR-CA310/L210
R803 1-216-809-11 METAL CHIP 100 5% 1/16W
(CA310)
R805 1-216-845-11 METAL CHIP 100K 5% 1/16W
(L210)
R806 1-216-845-11 METAL CHIP 100K 5% 1/16W
(L210)
R807 1-216-845-11 METAL CHIP 100K 5% 1/16W
(L210)
R808 1-216-845-11 METAL CHIP 100K 5% 1/16W
(L210)
R809 1-216-845-11 METAL CHIP 100K 5% 1/16W
(L210)
R810 1-216-845-11 METAL CHIP 100K 5% 1/16W
R811 1-216-864-11 SHORT 0
R850 1-216-864-11 SHORT 0
R851 1-216-864-11 SHORT 0
R853 1-216-864-11 SHORT 0
R855 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
< VARIABLE RESISTOR >
RV100 1-241-768-11 RES, ADJ, CARBON 220K
< SWITCH >
S1 1-692-431-21 SWITCH, TACTILE (RESET)
< THERMISTOR >
TH800 1-801-792-21 THERMISTOR, POSITIVE (CA310)
< TUNER >
TU100 1-693-523-11 FM/AM TUNER UNIT (FAE370-E01)
< VIBRATOR >
X1 1-795-134-11 VIBRATOR, CRYSTAL (18.432MHz)
X4 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
X200 1-579-242-11 VIBRATOR, CRYSTAL (4.332MHz)
**************************************************************
MISCELLANEOUS
**************
6 1-757-662-11 CORD (WITH CONNECTOR) (ISO) (POWER)
(CA310: AMBER/L210)
6 1-757-662-21 CORD (WITH CONNECTOR) (ISO) (POWER)
(CA310: GREEN)
66 1-694-696-31 CONDUCTIVE BOARD, CONNECTION
70 1-786-098-11 SWITCH, SHEET
F901 1-532-877-11 FUSE (BLADE TYPE) (AUTO FUSE) (10A)
HP901 1-500-661-11 HEAD (PLAYBACK)
LCD900 1-804-512-11 DISPLAY PANEL, LIQUID CRYSTAL
M901 1-763-507-11 MOTOR (CAPSTAN/REEL)
S901 1-771-928-11 SWITCH (SLIDE) (DIRECTION)
S902 1-771-926-11 SWITCH (LEAF) (FF/REW)
S903 1-771-927-11 SWITCH (LEAF) (TAPE DETECT)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-782-09 SCREW +PTT 2X5 (S)
#2 7-685-533-19 SCREW +BTP 2.6X6 TYPE2 N-S
#3 7-685-794-09 SCREW +PTT 2.6X10 (S)
#4 7-685-106-19 SCREW +P 2X10 TYPE2 NON-SLIT
#5 7-621-775-10 SCREW +B 2.6X4
#6 7-627-553-27 PRECISION SCREW +P 2X2.5 TYPE3
#7 7-685-101-11 SCREW +PTP 2X3 NON-SLIT
#8 7-621-255-35 SCREW +P 2X5
#9 7-621-255-25 SCREW +P 2X4
#10 7-685-781-09 SCREW +PTT 2X4 (S)
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
3-225-220-11 MANUAL, INSTRUCTION (ENGLISH, FRENCH,
DUTCH, ITALIAN, GERMAN)
3-225-220-21 MANUAL, INSTRUCTION (ENGLISH, SPANISH,
SWEDISH, PORTUGUESE, GREEK)
3-225-220-31 MANUAL, INSTRUCTION (ENGLISH, CZECH,
POLISH, TURKISH, RUSSIAN) (L210)
3-225-221-11 MANUAL, INSRTUCTION, INSTALL (ENGLISH,
FRENCH, DUTCH, ITALIAN, GERMAN)
3-225-221-21 MANUAL, INSRTUCTION, INSTALL (ENGLISH,
SPANISH, SWEDISH, PORTUGUESE, GREEK)
3-225-221-31 MANUAL, INSRTUCTION, INSTALL (ENGLISH,
CZECH, POLISH, TURKISH, RUSSIAN) (L210)
X-3378-490-1 CASE (PANEL) ASSY (for FRONT PANEL)
************************************************************
MAIN
Ver 1.2 2001.05
