Maintenance and Troubleshooting DLM-E 3kW & 4kW Series Power Supplies
5-4 M362000-01 Rev E
5.4 Ordering Parts
Do not substitute parts without first checking with the manufacturer’s Service Department. Parts
may be ordered from the factory , using the following information:
AMETEK Programmable Power
9250 Brown Deer Road
San Diego, CA 92121-2294
Toll free in North America: 1-800-733-5427
Direct: (858) 450-0085
Fax: (858) 458-0267
E-mail: sales@programmable
power.com
www.programmablepower.com
Note: When ordering parts please include the m
odel number and serial number of the unit with
your order.
5.5 Fuse Ratings
Table 5–3 provides a listing of Fuse Ratings.
Reference Designator Fuse Type Rating Size Option
F1, 2, 3 (Rear Panel) Fast Acting, AC F, 25A, 600V 13/32" x 1½ Std
F1, 2, 3 (Rear Panel) Fast Acting, AC F, 10A, 600V 13/32" x 1½ M1
F1, 2, 3 (Rear Panel) Fast Acting, AC F, 8A, 600V 13/32" x 1½ M2
F1 (Inside Chassis) Fast Acting, DC F, 15A, 600V 13/32" x 1½ —
F5, 6 Slow Blow, AC 2A, 250V 5 x 20 mm Leaded —
F7 Fast Acting, DC 0.5A, 125V PCB —
Table 5–3. Fuse Ratings
