A flour unit
ref. 5
Photo 1
is located above the outfeed belt and can be
switched on or off when the machine is running by means of a lever switch
positioned on the unit itself.
The quantity of flour per unit time delivered onto the belt, and hence onto the
product, can be adjusted with the knob on the front of the flour unit.
The long version of the outfeed belt can be folded back on itself when the
machine is at rest simply by lifting it with one hand, in order to reduce the
overall dimensions of the machine.
Finally, the version of the machine with geared motor marked “R” can
produce pieces in either 1 or two rows (obtainable product weights change
of course).
The following devices are located on the control panel
ref. 1
Photo 2
(see
Fig. 1
):
Ref. 1:
emergency stop pushbutton
Ref. 2:
run pushbutton
Ref. 3:
main stop pushbutton
Ref. 4:
power ON warning light (white)
Ref. 5:
divider only stop pushbutton
Ref. 6:
oil alarm warning light (red)
The following control and adjustment devices are also located on the
machine:
z
Handwheel
ref. 2
Photo 2
: for adjusting production speed or number of
pieces per unit time for the same number of rows (see para. 3.6).
z
Handwheel
ref. 3
Photo 2
: for adjusting the weight of the dough pieces.
z
Main switch
ref. 4
Photo 2
located on the electrical panel.
