Sottoriva SVP 0-E - Wiring Diagrams; Power Wiring Diagrams; 4.8.1.1 230 V 50 Hz VERSION; Electrical Control Diagrams

SVP 0/1/2/3-E - Code: 3529.0091.01
Rev. 0
dated 19/06/2001
16-IV

PT
601

PP
601

GC
601
Technical Assistance Service
Tel. (+39) 0445.595.111
33
4.8 Wiring diagrams
The full, detailed electrical documentation comes supplied with the machine,
inside the electrical panel.
4.8.1
Power wiring diagrams
4.8.1.1
230 V 50 Hz VERSION
4.8.1.2
400 V 50 Hz VERSION
4.8.2
Electrical control diagrams
The information set out in this paragraph is common to the 230V and 400 V
versions.
