2.3 Overall dimensions and other specifications
Fig. 2
shows the dimensions of the machine; the diameter D of the hopper
mouth depends on its capacity as follows:
*
Diameters for SVP machines which can be combined with SC
SOTTORIVA lifting/turnover units; for SVP units that can be combined with
other machines, these diameters may vary even for the same hopper
capacity.
Table 1 shows the installed power and other characteristics data.
N
indicates the normal version and
R
indicates the version with geared
motor.
Table 1
2.4 Machine identification plate
Fig. 3
shows the data plate, and
Fig. 2
shows the position in which it is fixed
to the machine with rivets or screws. It is made of aluminium, with the data
indelibly stamped or screen printed on to it.
C
A
P
A
C
I
T
Y
(kg)
D
70
mm 560
160
mm 1100*
240
mm 1400*
SVP/0-E
SVP/1-E
SVP/2-E
SVP/3-E
N
R
N
R
N
R
N
R
Min/max pieces size (g)
90
900
30
200
200
1700
50
300
300
2700
100
500
500
4000
250
1000
Divider motor power (kW)
1.10
1.10
1.10
1.10
Machine Mass (kg)
660
675
680
700
