Soucy S-TECH 7016 - Page 23

NOTICE
4730AND4830MODELSONLY
Figure6.2MAINPARTLISTOFS-TECH7016FORJOHNDEERE4730AND4830
7B
4730 / 4830
7A
1
6
5
4
3
2
ITEM
PART#QTYDESCRIPTION
1
1160RQ44-2
2
S-TECH7016TRACK
28031032-0024-21
LEFTBRACKETASS'YJD4730
38031032-0025-21
RIGHTBRACKETASS'YJD4730
48032007-0150-11
SP-716LEFTFRAMEASS'Y
5
8032007-0160-11
SP-716RIGHTFRAMEASS'Y
68033030-0010-12
SP-716SPROCKETASS'Y
7A8033032-0060-12
JD4730SPROCKETADAPTOR
7B8033038-0001-12
JD4830SPROCKETADAPTOR
INSTALLATION,OPERATIONANDMAINTENANCEGUIDE
