6.3.2BRACKETINSTALLATIONFORJD4730AND4830
NOTICE
4730AND4830MODELSONLY
1.Installfrontrightbracket(A)onknuckle(B)withbolts(1and2),washers(3and8)andnuts(4).Thelongestpart
ofthebracketmustbeputforward(D).
2.Useenoughshims(5,6and7)tollthegapbetweenthebracketandknuckle.Ifpossibleusethesameamountof
shimsoneachsideoftheknuckle.
3.Handtightbolts.
4730 / 4830
ITEM PART # QTY
1 S1111_16090_0F7 2
2 S1111_16130_0F1 6
3 S4515_M160G_0DC 14
4 S4186_M160Q_097 6
5 8031032_0014_1 8
6 8031032_0015_1 8
7 8031032_0031_1 8
8 8031032_0019_1 4
D
9 7/86 3/8
B
C
A
8
6
2
2
1
5
7
3
4
2
2
1
ITEM
DESCRIPTION
A
BRACKET
B
KNUCKLE
CHOSEMANIFOLDBRACKET
