Soucy S-TECH 7016 - Page 45

4.Installreinforcements(1),newcaliperbrackets(2)andshims(3)onknucklewithbolts(8and9)andwashers(10).
5.Fillthegapbetweenrightbracket(4)andreinforcements(1)withshims(5and6).
6.Installbolts(7),washers(8)andnuts(11).
7.Torquebolts(7)then,bolts(7Aand12).
4730 / 4830
ITEM PART # QTY
1 8031032_0018_2 2
2 8031032_0022_1 1
3 8031032_0023_1 1
4 8031032_0004_2 1
5 8031032_0021_1 2
6 8031032_0020_1 2
7 S1111_16090_0F7 8
8 S1111_20070_0F7 3
9 S1111_20090_0F7 3
10 S4515_M200H_0EC 6
11 S4186_M160Q_097 6
12 S1111_16130_0F1 6
12
7A
10
1
5
6
4
11
9
3
2
10
8
7
