7.4TRACKALIGNMENT
1.Dothisprocedureifrubbertracklugsareoverheating,andonaatsurface.
2.Drivethevehicleat30kmh(20mph)for2.5km(1.5miles)inordertodeterminewhetherthetrackisaligned.
3.Handfeelthelugstocheckiftheyareoverheating.Ifthelugsarenotoverheating,noadjustmentisrequired.Ifthe
temperatureishigherononeside,itmeansthelugsarerubbingagainstthewheels,aresultofthetrackpushing
onthatside.
NOTICE
•
THETEMPERATUREOFANOVERHEATINGLUGIS60°CORMORE.THELUGWILL
BETOOHOTTOKEEPABAREHANDONITFORMORETHANAFEWSECONDS.
•
IFTHETEMPERATUREISHIGHERONONESIDEBUTITISLOWERTHAN60°C(140
°C)AFTER10MINONTHEROAD,THESYSTEMCANBEOPERATEDANYWAY.
•
CHECKOVERHEATINGONBOTHSIDESOFTHELUG.
•
PROPERALIGNMENTISREQUIREDTOENSUREDURABILITYOFTHETRACK.
4.Thefrontalignmentcangenerallybecorrectedbyadjustingthetoe.Iftheinsidesurfaceofbothfronttracklugare
hot,increaseprogressivelythetoe-inuntilthetemperatureoneachsideareeven.Dotheoppositeifheatisonthe
outsideofbothlugs.trackdeection.
5.Alignmentcanalsobesetbymodifyingthecamberoftheundercarriage,proceedasfollow;
6.Turnthesprocketuntilthereisaccessforthepivotaxlebolts.
