6.3BRACKETINSTALLATION
6.3.1BRACKETINSTALLATIONFORJDR4030
NOTICE
R4030ANDR4038MODELSONLY
1.Installfrontrightbracket(A)onknuckle(B)withbolts(1)andwashers(2).Thelongestpartofthebracketmustbe
placedforward(C).
2.Useenoughshims(3,4,5,6,7and8)tollthegapbetweenthebracketandknuckle.Ifpossibleusethesamenumber
ofshimsoneachsideoftheknuckle.
3.Torquebolts.
ITEM PART # QTY
1 S1111_16090_0F7 6
2 S4515_M160G_0DC 6
3 8031027_0210_1 2
4 8031027_0200_1 2
5 8031027_0190_1 2
6 8031027_0730_1 2
7 8031027_0710_1 2
8 8031027_0720_1 2
1
2
5
7
8
6
4
3
B
A
13 3/8
9 7/8
C
R4030 / R4038
ITEM
DESCRIPTION
A
BRACKET
B
KNUCKLE
INSTALLATION,OPERATIONANDMAINTENANCEGUIDE
36
