7.2FRONTTRACKKITPARALLELISMADJUSTMENT

NOTE

•ApplicabletoFRONTframeonly.

•Dotheadjustmentonaatsurface.

•Measurethedistancefromtheidlerwheelhubatthefrontandthebackoftheundercarriage.

1.Useatapetomeasurethedistancebetweentheframesattheirfrontandback.

2.Tracksmustbetoe-inbetween1/8and3/8inch(3to10mm).

3.Toadjustthetoe-inproceedsaccordingtoyoursprayeroperatormanual.
