Soucy S-TECH 7016 - S-Tech 7016 Track System Specifications

1.1S-TECH7016TRACKSYSTEMSPECIFICATIONS
Figure1.1S-TECH7016RearViewMeasurements
ITEM
DESCRIPTIONVALUEMM(IN)
A
CLEARANCEONTRACK1626(64)
B
OVERALLWIDTH3658(144)
COVERALLHEIGHTONTRACKS4090(161)
D
OVERALLHEIGHTONTRACKS(AIRBAGDEFLATED)3990(157)
E
OVERALLLENGHT9220(363)
INSTALLATION,OPERATIONANDMAINTENANCEGUIDE
3
