2.1PRESENTATION
•Thisguidecontainstheinformationrequiredforsafelyinstalling,operatingandmaintainingyourSoucyTracksystem.
Pleasereadthisguidecarefullytolearnandunderstandhowtocorrectlyinstall,operateandservicetheTracksystem.
Failuretodosocouldresultinpersonalinjuryorequipmentfailure.
•Familiarizeyourselfwiththeinstructionsbeforeyouproceedwiththeinstallation,operationandmaintenanceofthe
tracksystem.
•Keepthisguidehandywhileinstalling,operating,andmaintainingyoursystem.
•Thisequipmentshallbeusedforagriculturaloperationsonly.ContactSoucyTrackifyouwishtouseitforother
purposes.
•Runningthesprayeroveragrarianlandusingagriculturalrubbertracksensuresthatthesurfaceofthefarmlandis
protectedfromsignicantdegradation.
NOTICE
THISGUIDEMAYBEREVISEDBASEDONOPERATIONALEXPERIENCE,FEEDBACKFROM
USERS,ANDDESIGNIMPROVEMENTSOFTHETRACKSYSTEM.
2.2HOWTOUSETHISGUIDE
NOTICE
THISGUIDEREFLECTSTHESYSTEMCONFIGURATIONATTIMEOFPRINTING.PHOTOSAND
FIGURESARETYPICAL.SOUCYTRACKRESERVESTHERIGHTTOMODIFYTHESYSTEM
ATANYTIMEWITHOUTPRIORNOTICE.YOURSYSTEMMAYSLIGHTLYDIFFERFROMTHE
EQUIPMENTSHOWN.
2.3ECDECLARATIONOFCONFORMITY
•EuropeanoperatorscanndacopyoftheECDeclarationofConformity(MachineryDirective)attheendofthisguide.
2.4SYSTEMDESCRIPTION
•Thetracksystemconsistsofarubbertracksupportedbyawheeledundercarriageanddrivenbyasprocketsecured
tothetractorwheelhub.Thepivotingframeisretainedbyapin(pivotaxle)onanattachmentsecuredtotheaxle
housing(seenextgure).Movementofthetrackisensuredbythedrivingsprocketteethpushingontheinternal
trackteethwhenthetractorismoving.
