3.Removewheel,fender,brakecaliper,diskandcaliperbrackets.
NOTICE
CALIPERHYDRAULICHOSEDOESNOTNEEDTOBEDISCONNECTED.
4.UseaM20x2.5taptoremovedustandrustonrearknucklecaliperbracketholes.
5.Loosenhydraulichosemanifoldandremovemanifoldbracket(A)fromknuckle.
NOTICE
AGAPOF1.5INCHESBETWEENTHEBRACKET(A)ANDTHEKNUCKLE(B)ISREQUIRED
FORTHEINSTALLATION.
B
A
