NOTICE
R4030ANDR4038MODELSONLY
Table6.2PARTLISTOFREARBRACKETFORJOHNDEERER4030ANDR4038(8031027-0800-1)
ITEM
PART#QTYDESCRIPTION
18031027-0190-12
SIDESHIMLONG#1
28031027-0200-12
SIDESHIMLONG#2
38031027-0210-12
SIDESHIMLONG#3
48031027-0220-11
SP-716MAINPIVOTAXLE
5
8031027-0230-12
LOCKINGDEVICE
68031027-0240-12
SAFETYPLATE
7
8031027-0320-12
FRONTSHIM#1
88031027-0330-12
FRONTSHIM#2
98031027-0340-14
FRONTSHIM#3
108031027-0530-14
SHIM#4PIVOT
118031027-0710-12
SIDESHIMSMALL#1
128031027-0720-12
SIDESHIMSMALL#2
138031027-0730-12
SIDESHIMSMALL#3
148031027-0740-12MAINPLATE
158031027-0790-16
SHIMMAINPLATE
168031027-0810-11
R4030RIGHTPAINTEDBRACKET
16A8031027-0860-11
R4030LEFTPAINTEDBRACKET
178031027-0840-12
SHIM#2(SHAFTCAMBER)
188031027-1670-14
SHIM#6(SHAFTCAMBER)
198031027-1700-11
LIFTINGBRACKETPAINTEDASS'Y
20
S1111-24120-0F1
2
HEX.BOLTCL10.9PZM24-3.0X120mm
21
S1111-16055-0F7
10
HEX.BOLTCL10.9ZnNiM16-2.0X55(DIN931)
22
S1111-16090-0F7
6
HEX.B.CL10.9ZnNiM16-2.0X90mm(DIN931)
23
S1111-20060-0F7
6
HEX.BOLTZnNiCL10.9M20-2.5X60mm
24
S1111-20070-0F7
4
HEX.BOLTZnNiCL10.9M20-2.5X70mm
25
S4515-M160G-0DC
6
LOCKWASHERHDM16ID17OD27.4X4.8(DIN127B)
26
S4515-M200H-0EC
6
LOCKWASHERHDM20ID21.2XOD33.6X5.74(DIN127)
