2.Installpivotaxle(1)inframe(2)withholesonthepivotaxleup.Insertshims(3)onthepivotaxle.Alignframewith
rightbracket(4)andcarefullylowersprayeronframe,ensuringthatpivotaxletsintherightbracket.
3.Installbolts(5)throughpivotaxleintotherightbracket.Torquebolts.
4.Installlockingdevices(6)andsafetyplates(7)withbolts(8).
ITEM PART # QTY
1 8031027_0220_1 1
2 8032007_0160_1 1
3 8031027_0530_1 4
4
S1111−24120−0F1
2
5 8031027_0240_1 2
6 8031027_0230_1 2
7 S1111_20070_0F7 4
2
3
5
6
1
4
7
