3.Verifythatthereisenoughgapbetweenrollerswheelsandsprocket.Gapshouldbeatleast3/8in(10mm)to
ensuresafeoperation.
B − B
B
B
MIN 3/8 (9.5mm)
ITEM
DESCRIPTION
B
MIN3/8”(9.5mm)onbothside
4.Tomodifythesprocketpositionregardingtotheundercarriage;changearrangementofthelateralshims(1)onthe
pivotaxle(2).Notethataddingshimsontheoutsideoftheframewillmovetheundercarriagetotheinteriorofthe
sprayer.
5.InstalltheOEMnutsandtorquethem.
2
1
ITEM PART # QTY
1 8031027_0530_1 4
2 8031027_0220_1 1
