Spa Builders SC-CF-SBD - Electrical & Temperature Specifications

Specifications
Electrical Specifications
Input
Outputs
Pump 1
Pump 2
(blower)
Heater
Ozone
Light
240 V, 48 A, 60 Hz
120 V, 15 A, 60 Hz
(high) 120 V, 14 FLA / 80 LRA
(low) 120 V, 14 FLA / 80 LRA or
(high) 240 V, 14 FLA / 80 LRA
(low) 240 V, 14 FLA / 80 LRA
Connector: J&J or AMP
120 V, 14 FLA / 80 LRA or
240 V, 14 FLA / 80 LRA
Connector: J&J or AMP
120 V, 8.3 A or
240 V, 16.7 A
120V. 3A or
240 V, 3A
Connector: J&J or AMP
12 V, 1 A
Connector: Direct lamp socket assembly
Temperature Specifications
Operating
0 122°F
-17 50°C
-40 160°F
-40 70°C
Up to 80% non-condensing
Adjusted in 1° increments from 59° to 104°F (10° to 40°C)
Better than 1°F
Storage
Humidity
Set Point Adj.
Temp. Measure
