SC-CF-SBD Owner’s Manual28
Ozonator
Output Configuration
Configuration of
ozonator output
Your pack is configured at the factory to control a 120V ozonator.
If you want to use a 240V ozonator, you need to change the
white wire connector on the board. To do so:
1) Locate the ozonator
connector.
2) Using a pair of long-nose
pliers, unplug the white
wire of the ozonator
connector (P8) from the
board.
3) Reconnect the white
wire to P19 (see wiring
drawing). Make
sure the connector is
properly inserted.
Note:
The ozonator will be
activated only during
the filter cycle.
