Spa Builders SC-CF-SBD - Spa Control Electrical Wiring; Wiring Essentials

29SC-CF-SBD Owner’s Manual
Proper wiring of the electrical service box,
GFCI box and pack terminal block is essential.
Electrical Wiring
• Refer to supplied wiring diagrams.
Connections must be made by a certified electrician
Electrical Box GFCI
Pack Terminal Block
For 240 vac systems:
For 120 vac systems:
L2
N
G
L1
L2
N
G
L1
Green
White
Black
Red
White
White x
Green
Black
x Jumper supplied with the pack
• Warning: Total current ouput
cannot exceed total current input
rating!
