17SC-CF-SBD Owner’s Manual
Installation
Power Box
Power Box
The power box must be installed close to the spa side,
preferably under the spa, at a location where possibility of
water leaks is minimal.
It can be wall-mounted or installed directly on the floor
(or both at the same time).
Six holes on the back of your pack are provided to mount the
pack on a wall.
Four holes located on the pack feet can be used to fix it to the
floor.
Warning: Any physical damage to the enclosure arising from misuse,
abuse or improper installation will automatically void any liability of the
product.
Holes for wall-mounting
Holes for floor-mounting
Bottom viewFront view
