SC-CF-SBD Owner’s Manual14
Main Spa Side Control (K-19)
Installation
Installation
The first step in the installation procedure of the K-19 main spa side
control is to cut a hole directly on the edge of the spa.
The hole must be a 2
5/8
" by 6
3/8
" rectangle to allow the keypad box
to slide into position.
Mounting System
The keypad should be installed directly on the spa (or very close) for it
to be easily reached by the user.
Steps to follow:
1- Select the appropriate
location for the control unit.
2- Cut a 2
5/8
" by 6
3/8
"
rectangle on the edge of the
spa.
3- Peel off the double-faced
tape protective layer.
4- Insert the keypad and secure
it in place by pressing firmly
on the keypad.
Spa Side
6
3/8
"
2
5/8
"
Note: If the keypad is physically damaged, the spa must not be used and the
keypad should be replaced immediately.
