DVR-IP4CF
28
to trigger the alarm when hard disk is full (this setup is only active when the
system is under record status).
9. BUZZER TIME: Press《ENTER》button to setup the buzzer time to continuous
(CONT), and press any button to release this setup.
10. RELAY OUT TIME: Press《ENTER》button to setup the relay out time to
continuous (CONT), and press any button to release this setup.
8.5.1 SENSOR TYPE:
1. Cursor (>) position indicates the current selected position.
2. Press《←》and《→》button to move the cursor to the desired item (CH1~CH4).
3. Press《ENTER》button to make changes.
4. Press《MENU》button to exit “SENSOR SETUP” selection.
5. CHANNEL-1: Press《ENTER》button to setup “NO” (Normal Open) or
“NC” (Normal Close).
6. CHANNEL-2 ~ CHANNEL-4: Please follow the setup shown above (CHANNEL-1).
SENSOR SETUP ■■■
> CHANNEL-1 NOT INSTALLED
CHANNEL-2 NOT INSTALLED
CHANNEL-3 NOT INSTALLED
CHANNEL-4 NOT INSTALLED
PRESS (< >), THEN (ENTER)
PRESS (MENU) TO EXIT
