Spectrum DX3 User Manual

5
Travel Adjustment
MODE
ENTER
SYSTEM
1. From the Servo Reverse function, press the MODE key twice to access the Travel
Adjustment function (the STL or STR screen will appear).
Steering Adjustment
2. Rotate the steering wheel in the desired direction (left or right) to be adjusted.
INCREASE DECREASE
CLEAR
DIRECT
+ –
3. Press the INCREASE or DECREASE keys to select the desired travel value.
Throttle/ Brake Adjustment
4. Press the CHANNEL key once. FWD will appear on the screen.
CHANNEL
ENTER
SYSTEM
5. Press the INCREASE or DECREASE keys to select the desired travel value.
INCREASE DECREASE
CLEAR
DIRECT
+ –
6. Move the throttle trigger to full brake and hold, noting that the screen now displays
BRM. Adjust the brake value by pressing the INCREASE or DECREASE keys to obtain
the desired full brake position.
Channel 3 Adjustment
If third channel is not required, proceed to Step 8.
CHANNEL
ENTER
SYSTEM
7. Press the CHANNEL key once. F3+ will appear on the screen.
MODE CHANNEL
ENTER
SYSTEM
8. Move the grip dial A in the desired position and press the INCREASE or DECREASE
keys to select the desired travel value for the third channel.
9. Press the MODE and CHANNEL keys at the same time to exit the function mode.
DX3 Quick
Start Setup
(continued)
Indicates Current Adjustment Position
STR = Steering Right
STL = Steering Left
FWD = Forward Trigger
BRM = Reverse (brake) Trigger
F3+ = Third Channel (optional)
Indicates Current Value
str
100
TRV ADJ.
–
–
