SPHINX Project Eight Service Manual
35
Designator Part Type Description
CN2 4PIN Connector
CN2 5PIN Connector
CN2 XLR MALE Connector
CN20 CINCH Connector
CN21 XLR FEMALE Connector
CN22 XLR FEMALE Connector
CN23 XLR FEMALE Connector
CN24 XLR FEMALE Connector
CN3 4PIN Connector
CN3 XLR MALE Connector
CN4 8PIN Connector
CN4 XLR MALE Connector
CN5 CINCH Connector
CN6 CINCH Connector
CN7 CINCH Connector
CN8 CINCH Connector
CN9 CINCH Connector
D1 1N4004 Diode
D1 1N4148 Diode
D1 1N4148 Diode
D10 1N4148 Diode
D11 1N4148 Diode
D12 1N4148 Diode
D2 1N4004 Diode
D2 1N4148 Diode
D3 1N4004 Diode
D3 1N4148 Diode
D4 1N4004 Diode
D4 1N4148 Diode
D5 1N4004 Diode
D6 1N4004 Diode
D7 1N4004 Diode
D8 1N4004 Diode
D9 1N4148 Diode
IR1 IRIC Infrared receiver
J1 Jumper R Jumper
J2 Jumper R Jumper
J3 Jumper R Jumper
LD1 LD RD LED
LD1 LD RD LED
LD2 LD RD LED
LD2 LD RD LED
LD3 LD RD LED
LD3 LD RD LED
LD4 LD RD LED
LD4 LD RD LED
LD5 LD RD LED
LD6 LD RD LED
OPT1 OPTOUT optical output
OPT2 OPTOUT optical output
OPT3 OPTOUT optical output
P1 50R Var. Resistor
P2 50R Var. Resistor
R1 100R Resistor
R1 1R Resistor
