Designator Part Type Description
R1 27K4 Resistor
R1 4k75 Resistor
R10 1R Resistor
R10 1R00 Resistor
R10 4K75 Resistor
R100 20K0 Resistor
R101 80R6 Resistor
R102 10K0 Resistor
R103 40R2 Resistor
R104 10K0 Resistor
R105 40R2 Resistor
R106 10K0 Resistor
R107 40R2 Resistor
R108 10K0 Resistor
R109 40R2 Resistor
R11 15R0 Resistor
R11 1R Resistor
R11 600R Resistor
R110 5K23 Resistor
R111 20R0 Resistor
R112 5K23 Resistor
R113 20R0 Resistor
R114 5K23 Resistor
R115 20R0 Resistor
R116 5K23 Resistor
R117 20R0 Resistor
R118 2K61 Resistor
R119 10R0 Resistor
R12 15R0 Resistor
R12 1R Resistor
R12 600R Resistor
R120 2K61 Resistor
R121 10R0 Resistor
R122 2K61 Resistor
R123 10R0 Resistor
R124 2K61 Resistor
R125 10R0 Resistor
R126 1K30 Resistor
R127 0R00 Resistor
R128 1K30 Resistor
R129 0R00 Resistor
R13 18R0 Resistor
R13 1R Resistor
R13 1R00 Resistor
R130 1K30 Resistor
R131 0R00 Resistor
R132 1K30 Resistor
R133 0R00 Resistor
R134 649R Resistor
R135 634K Resistor
R136 649R Resistor
R137 634K Resistor
R138 649R Resistor
R139 634K Resistor
R14 10K0 Resistor
R14 18R0 Resistor
R14 1R00 Resistor
R140 649R Resistor
R141 634K Resistor
R142 2K00 Resistor
R143 2K00 Resistor
R144 2K00 Resistor
R145 2K00 Resistor
R146 2K00 Resistor
R147 2K00 Resistor
R148 2K00 Resistor
R149 2K00 Resistor
R15 10R0 Resistor
R15 15R0 Resistor
